Crown CDi 4|300 Power Amplifier
SKU:
CRO0339
Crown
The CDi DriveCore Series is a cost-effective amplifier line based upon Crown DCi platform technology and provides a power amplifier solution that captures industry trends of higher channel density & feature-rich design at a reasonable cost with integrated DSP and front panel display. Representing the continued development of Crown's installation amplifiers, it has similar features to DCi but is tailored to meet the needs of a selective market segment that requires a balance of features, price, and performance. Features such as 100Vrms and 4 channel amplifiers will appeal to international markets. All models have network capability, and each model has an analog and an analog + BLU link version, making this series a high-value but affordable option for contractors.
- Convenient and flexible advanced features, modern energy-efficient design, and easy to use
- Proven advanced technology at an affordable price
- Low-impedance functionality (4/8) and High-impedance 70V and 100V output without transformers
- Universal Power Supply enables flexible use for audio installations worldwide
| BLU link | No |
| Channels | 4 |
| Sensitivity (for full rated power at 8 ohms) | 0.7V RMS |
| Rated Power Output (per channel @ 4 ohms) | 300W |
| Analog Input Signal to Noise Ratio (ref. rated power, 100V, 20Hz - 20kHz) at 8 ohms) | > 104dB |
| THD (full rated power, 20 Hz - 20 kHz) | 0.35% |
| Damping Factor (20 Hz to 100 Hz) | > 1000 |
| Frequency Response (8, 20 Hz - 20 kHz) | +/-0.5dB |
| Crosstalk (below rated power) 20 Hz to 1 kHz | > 80dB |
| Input Impedance (nominally balanced, nominally unbalanced) | 20 k balanced, 10 k unblanced |
| Dimensions (inches) (W x H x D) (depth not including 1.3 inch front panel protrusion) | 19 x 3.5 x 12.25 |
| Weight | 16.13 lbs (7.31 kg) |
| Power Supply Connector | Standard IEC type 320 inlet for detachable connector 100 - 240V~ |
