BiAmp T20IP Waterproof Transformer 8 ohms to 100V Tapped to 20/10/5/2.5W

SKU: BiAmp T20IP
BiAmp

The T20IP is a small built-in 100 volt line transformer, designed to make it possible to convert a standard 8 ohms loudspeaker into a 100 volt line speaker with selectable power taps (2.5 5 10 and 20 watts in 100 volt).

This transformer will open a lot of additional speaker models to the 100 volt speaker range. The only thing that needs to be done is to connect the T20IP transformer between the 100 volt amplifier and the low impedance loudspeaker. Another great advantage of the T20IP is that its packed inside a humidity resistant box.

Product Features

• 8 ohms to 100 volt transformer
• Several power tappings from 2.5 up to 20 watts
• Packed within humidity resistant box

Product Specifications

General

• Input: 8 ohms
• Output: 100 volt
• 100v transformer power taps: 20 - 10 - 5 2.5 watts

Physical & Dimensions

• Height: 53mm
• Width: 112mm
• Depth: 58mm
• weight: 0.53kg
