Citronic H1600 Hybrid Power Amplifier, 2 x 650w @ 4ohm 172.117UK

SKU: 172.117UK
Citronic

Lightweight power amplifiers in a 19 rack-mountable housing for generating high sound pressure levels in medium to large sound reinforcement systems. H-series amplifiers employ a new hybrid class-H architecture, which combines the streamlined efficiency of a digitally controlled power section design with the power delivery and stability of a professional class-H output stage. Comprehensive internal protection monitors any thermal or overload conditions, automatically mutes at power on/off and provides active inrush limiting. A digital display continually shows the supply voltage, internal temperature and output level. A fully balanced signal path has 3 switchable input sensitivity levels to match different audio sources and the amplifier section can be set to operate in Stereo, Parallel or Bridge modes. A switchable 120Hz low-pass filter can be selected for use with subwoofers, avoiding the need for a separate crossover and saving additional expense and rack space. Speaker outputs can be connected using 1 or 2 Speakon leads as required. H-series amplifiers provide immediate and dynamic power on demand for sound contractors and PA installers that need dependable service with optimum sound quality.

Hybrid class-H circuit design

Digitally controlled and monitored power section

Switchable 120Hz low-pass crossover

Backlit LCD status display

Full internal thermal and overload protection

Stable down to 2 Ohms (4 Ohms bridged)

Power supply 200-240Vac, 50Hz (IEC)

Amplifier : construction Hybrid Class-H

Protection Short/open circuit, thermal, RF, DC fault, on/off mute, active inrush

Frequency response 20Hz-20KHz 0.5dB

THD +N 0.2%

S/N ratio -95dB

Damping factor >700

Input sensitivity 1.0V - 1.4V - 2.0V switchable

Input impedance 20Kohm (balanced),10Kohm (unbalanced)

Crossover Switchable full range or fixed 120Hz low-pass filter

Dimensions 483 x 361 x 44 mm (1U)

Fuse T6AL 250V

Power rms @ 8 Ohms 2 x 450W

Power rms @ 4 Ohms 2 x 650W

Power rms @ 2 Ohms 2 x 800W (40ms burst 1kHz sine)

Power rms bridge @ 8 Ohms 1200W

Power rms bridge @ 4 Ohms 1600W (40ms burst 1kHz sine)

Weight 6.8kg
