Wharfedale WLA-15MX Stage Monitor, Black - Wharfedale

roll over the image to zoom in

Wharfedale WLA-15MX Stage Monitor, Black

SKU:
Wharfedale

Wharfedale WLA-15MX Stage Monitor, Black

  • 3.0” Neo HF compression drivers with high flux density
  • Rotatable horns for horizontal or vertical applications
  • Multiple NL4MP speakON compatible connectors on top, side and rear
  • 35 mm pole socket for vertical performance
  • 15 mm Baltic birch plywood construction.
£0.00
£0.00
Earn0
reward points
Add To Your Wishlist

Oh No! This product is out of stock. Would you like to know when it's avaliable again?

  • Product Features
    • 15″ 2-way passive floor monitor
    • 4.0″ LF voice coil
    • 3.0″ Newly designed Neo HF compression driver
    • Baltic Birch plywood construction
    • Rotatable waveguide
    • 35 mm pole socket
    • 700 watts AES (RMS)
    • 1400 watts Programme
    • 2800 watts Peak
    • Max SPL @ 1 meter 134 dB
  • Technical Specification
    Model NameWLA-12MXWLA-15MX
    System TypePassivePassive
    ConfigurationTwo-way MonitorTwo-way Monitor
    Frequency Response (+/-3 dB)55-20 KHz45-20 KHz
    Frequency Range (- 10 dB)50-20 KHz40-20 KHz
    Sensitivity 2.83 V / 1 M98 dB99.5 dB
    Calculated Maximum SPL @1 M131 dB134 dB
    System Rated Impedance8 Ω8 Ω
    Low Frequency Transducer

    LF Size (mm / inches)331 mm / 12″390 mm / 15″
    LF Voice Coil Size (mm / inches)76.2 mm / 3″102 mm / 4″
    LF Magnet Materialferriteferrite
    LF Frame Materialaluminiumaluminium
    Rated Impedance8 Ω8 Ω
    LF Power re:AES2-2012500 W700 W
    High Frequency Transducer

    HF Driver TypeCompression DriverCompression Driver
    Coil Size (mm / inches)75 mm / 3.0″75 mm / 3.0″
    Exit Size (mm / inches)35.5 mm / 1.4″35.5 mm / 1.4″
    HF Magnet MaterialNdFeBNdFeB
    Diaphragm MaterialTitaniumTitanium
    Rated Impedance8 Ω8 Ω
    HF Power re:AES2-201290 W90 W
    Waveguide Typesquaresquare
    Nominal Coverage (H x V)90° x 60° (Rotatable)90° x 60° (Rotatable)
    Power

    System Continuous Power (w)500 W700 W
    System Programme Power (w)1000 W1400 W
    System Peak Power (w)2000 W2800 W
    Input Connector4 x NL4MP
    (speakON Compatible)    		4 x NL4MP
    (speakON Compatible)
    RiggingM10 x 10M10 x 10
    pole mount35 mm35 mm
    handles2 on Sides2 on Sides
    Enclosure

    cabinet typepolygonpolygon
    Enclosure Material and finish15 mm plywood15 mm plywood
    Colour Optionsblack paintblack paint
    Grille Material & Finishsteelsteel
    Dimensions – Unpacked (mm / inches):

    Height658 mm / 25.9″723 mm / 28.5″
    Width372 mm / 14.6″432 mm / 17.0″
    Depth400.1 mm / 15.8″434 mm / 17.1″
    Dimensions – Packed (mm / inches):

    Height746 mm / 29.4″811 mm / 31.9″
    Width442 mm / 17.4″480 mm / 18.9″
    Depth470 mm / 18.5″512 mm / 20.2″
    Weight

    Net Weight (kg / lbs)25.5 kg / 56.1 lbs31.9 kg / 69.9 lbs
    Gross Weight (kg / lbs)27.8 kg / 61.2 lbs34.7 kg / 76.3 lbs
