Wharfedale WLA-12MX Stage Monitor, Black

SKU:
Wharfedale

Wharfedale WLA-12MX Stage Monitor, Black

Around the world WLA series line arrays are used in demanding environments. Systems expand and customers demand larger rigs with more configuration flexibility.

To answer this need Wharfedale Pro introduce WLA series floor monitors. Constructed of the finest 15mm Baltic birch plywood and using custom Wharfedale Pro drivers with high flux densities, they have the performance and construction quality for relentless touring and demanding on-stage abuse.

£0.00
£0.00
Earn0
reward points
Add To Your Wishlist

Oh No! This product is out of stock. Would you like to know when it's avaliable again?

  • Product Features

    KEY FEATURES

    • 3.0” Neo HF compression drivers with high flux density
    • Rotatable horns for horizontal or vertical applications
    • Multiple NL4MP speakON compatible connectors on top, side and rear
    • 35 mm pole socket for vertical performance
    • 15 mm Baltic birch plywood construction.


    • 12″ 2-way passive floor monitor
    • 3.0″ LF voice coil
    • 3.0″ Newly designed Neo HF compression driver
    • Baltic Birch plywood construction
    • Rotatable waveguide
    • 35 mm pole socket
    • 500 watts AES (RMS)
    • 1000 watts Programme
    • 2000 watts Peak
    • Max SPL @ 1 meter 131 dB
  • Technical Specification
    Model NameWLA-12MXWLA-15MX
    System TypePassivePassive
    ConfigurationTwo-way MonitorTwo-way Monitor
    Frequency Response (+/-3 dB)55-20 KHz45-20 KHz
    Frequency Range (- 10 dB)50-20 KHz40-20 KHz
    Sensitivity 2.83 V / 1 M98 dB99.5 dB
    Calculated Maximum SPL @1 M131 dB134 dB
    System Rated Impedance8 Ω8 Ω
    Low Frequency Transducer

    LF Size (mm / inches)331 mm / 12″390 mm / 15″
    LF Voice Coil Size (mm / inches)76.2 mm / 3″102 mm / 4″
    LF Magnet Materialferriteferrite
    LF Frame Materialaluminiumaluminium
    Rated Impedance8 Ω8 Ω
    LF Power re:AES2-2012500 W700 W
    High Frequency Transducer

    HF Driver TypeCompression DriverCompression Driver
    Coil Size (mm / inches)75 mm / 3.0″75 mm / 3.0″
    Exit Size (mm / inches)35.5 mm / 1.4″35.5 mm / 1.4″
    HF Magnet MaterialNdFeBNdFeB
    Diaphragm MaterialTitaniumTitanium
    Rated Impedance8 Ω8 Ω
    HF Power re:AES2-201290 W90 W
    Waveguide Typesquaresquare
    Nominal Coverage (H x V)90° x 60° (Rotatable)90° x 60° (Rotatable)
    Power

    System Continuous Power (w)500 W700 W
    System Programme Power (w)1000 W1400 W
    System Peak Power (w)2000 W2800 W
    Input Connector4 x NL4MP
    (speakON Compatible)    		4 x NL4MP
    (speakON Compatible)
    RiggingM10 x 10M10 x 10
    pole mount35 mm35 mm
    handles2 on Sides2 on Sides
    Enclosure

    cabinet typepolygonpolygon
    Enclosure Material and finish15 mm plywood15 mm plywood
    Colour Optionsblack paintblack paint
    Grille Material & Finishsteelsteel
    Dimensions – Unpacked (mm / inches):

    Height658 mm / 25.9″723 mm / 28.5″
    Width372 mm / 14.6″432 mm / 17.0″
    Depth400.1 mm / 15.8″434 mm / 17.1″
    Dimensions – Packed (mm / inches):

    Height746 mm / 29.4″811 mm / 31.9″
    Width442 mm / 17.4″480 mm / 18.9″
    Depth470 mm / 18.5″512 mm / 20.2″
    Weight

    Net Weight (kg / lbs)25.5 kg / 56.1 lbs31.9 kg / 69.9 lbs
    Gross Weight (kg / lbs)27.8 kg / 61.2 lbs34.7 kg / 76.3 lbs
