Trantec S4.04A UHF Headworn System with HM33 Head microphone CH70

SKU: tra S4.04-A-EB-GD5
Trantec

Trantec S4.04A UHF Headworn System with HM33 Head microphone CH70

UHF 4 Frequency Standard Headset Radio Microphone System (MIC-SJ33)

The S4.04 Series Standard Headset System comes with a Beltpack Transmitter, a Headset Microphone (MIC-SJ33) and a UHF Wireless Tuner. It is available on channel 70 with 4 switchable licence free frequencies and fully synthesized PLL quartz tuning technology.

Product Features

• Wireless beltpack, headset microphone and receiver system
• Broadcasts on free channel 70 frequency
• Channel number setting by manual
• Channel number setting by Infrared synchronization
• Channel scan
• Beltpack battery lasts approximately 10 hours

Receiver

• Diversity Reception: Antenna Diversity
• Sensitivity: 10uV at 45dBA, S/N
• Squelch: Tone SQ, Carrier SQ, Noise SQ
• Audio Frequency Response: 50Hz – 15kHz
• Audio Output Level (Max.)
  • Balanced (XLR socket): -20dBu
  • Unbalanced (1/4″ jack socket): 10dBu
• Power Supply: 12 VDC 500mA
• Dimensions: 215(W) x 39(H) x 102(D)mm
• Weight: 480g

Beltpack Transmitter

• RF Carrier Power: 10mW
• Audio Frequency Response: 50Hz – 15kHz
• Audio Input Level: -6dBV (maximum), mic gain 0dB
• Battery Life: Approximately 10 hours
• Power Supply: 1 AA size battery, 1.5V
• Finish: Resin, coating
• Dimensions: 62(W) x 100(H) x 25(D)mm
• Weight: 85g with battery
