TOA A-3212DM A-3200 Series 120 Watt Digital Mixer Amplifier, MP3 & Bluetooth

SKU: A-3212DM
TOA

TOA A-3212DM A-3200 Series 120 Watt Digital Mixer Amplifier, MP3 & Bluetooth

A-3212DM is a high performance yet cost-effective mixer power amplifier equipped with MP3 and Bluetooth function. Ideal for broadcasting, paging, or background music in schools, offices, shops, houses of worship and large ballrooms.

• Four (Five microphones on A-324DME-AS) microphone inputs, two AUX inputs and one recording output.
• Speaker output of constant voltage distribution system (100V) & low impedance (4 OHMS).
• Operates on AC power.
• Muting function.
• Independent input volume control and master volume control.
• Independent tone control of boost and cut type for both high and low frequency.
• MIC 1 equipped with phantom power for condenser microphone and also an option for Chime Microphone.
• Current limiter circuitry protects the transistor and thermal protection circuitry prevents a failure due to overheat.
• All MIC inputs are electronically-balanced input.
• Additional features such as built-in MP3 Player, zone Selector and 5 Bands equalizer.
• Power Source: ?100 - 240 V AC, 50/60Hz
• Rated Output: ?120 W
• Power Consumption: 44 W (AC operation at 1/8 maximum output without clip)
• Frequency Response: ?50 - 20,000 Hz
• Input MIC 1: ?1 mV (-60 dB*), 600 , balanced, phone jack, selectable to RJ45
• MIC 2-3: ?1 mV (-60 dB*), 600 , balanced, phone jack
• MIC 4: ?1 mV (-60 dB*) 600 , balanced, phone jack, selectable to AUX 1
• AUX 1: ?100 mV (-20 dB*), 10 k, unbalanced, RCA pin jack, selectable to MIC 4
• AUX 2: ?100 mV (-20 dB*), 10 k, unbalanced, RCA pin jack
• MP3: ?LED Display, Support USB, SD/MMC card (up to 32GB), Bluetooth, Radio FM, Record
• Output Speaker out: ?Speaker Output in screw type terminal
• Direct line (selectable): ?83 (100 V) or 4
• Rec out: ?0 dB*, 600 , unbalanced, RCA pin jack
• Phantom Power: ?DC +21 V (MIC 1)
• S/N Ratio: ?Over 60 dB
• Total Harmonic Distortion: ?Under 1% at 1 kHz, 1/3 rated power
• Tone Control Bass: ?10 dB at 100 Hz
• Treble: ?10 dB at 10 kHz
• Muting MIC 1: ?Mutes other input signals by 0-30 dB attenuation
• Indicator: ?Power, Signal, Peak, Protect
• Ventilation: ?Natural Air Cooling
• Finish Panel: ?ABS resin, black
• Case: ?Steel plate, black
• Dimensions: ?420 (W) ? 100.9 (H) ? 357 (D) mm
• Weight: ?4.6 kg
• Accessory: ?Antenna FM radio (1m) x 1
