DAP DMX/AES-EBU cable 6m - 3P - Rean XLR/M 5P to XLR/F 5P - DAP

DAP FLR09 - DMX/AES-EBU 3 Pin Rean DMX Lead - 6m

roll over the image to zoom in

DAP FLR09 - DMX/AES-EBU 3 Pin Rean DMX Lead - 6m

DAP DMX/AES-EBU cable 6m - 3P - Rean XLR/M 5P to XLR/F 5P

SKU: FLR096
DAP

The DAP FLR09 is a professional-grade 6-metre DMX/AES-EBU cable engineered for reliable and high-performance digital signal transmission. Built with DAP’s DIG-110 110-ohm digital cable and fitted with premium Rean RC3 connectors, this cable delivers low-impedance, interference-free connectivity essential for demanding lighting and audio environments.

The DIG-110 features a durable braided shield to ensure minimal signal loss and maximum protection from interference. The RC3 connectors offer silver-plated contacts for optimal signal clarity and a sleek, black zinc housing that combines durability with a professional appearance. For added convenience, each cable includes a transparent heat-shrink label sleeve for clear identification and a hook-and-loop fastener to keep your setup neat and organized.

Whether you’re working on stage, in the studio, or during live events, the FLR09 6m provides dependable, high-quality connections you can count on.

£15.05
£20.06
Earn0
reward points
Add To Your Wishlist

Oh No! This product is out of stock. Would you like to know when it's avaliable again?

  • Product Features

    • Professional-Grade Performance: Designed for high-quality DMX and AES/EBU digital signal transmission in professional audio and lighting setups.

    • 6-Metre Length: Ideal for medium-distance connections on stage, in the studio, or at live events.

    • DAP DIG-110 Cable: 110-ohm digital cable with braided shielding ensures low-impedance, interference-free signal transmission.

    • Rean RC3 Connectors: Fitted with silver-plated contacts for optimal signal clarity and reliable connections.

    • Durable Black Zinc Housing: Robust and sleek, perfect for professional environments.

    • Transparent Label Sleeve: Includes a heat-shrink label sleeve for easy cable identification.

    • Hook-and-Loop Fastener: Keeps cables organized and tangle-free during storage and transport.

  • Technical Specification
    Specification
    Connector 1XLR 3 Pin
    Connector 2XLR 3 Pin
    Brand ConnectorsREAN
    Impedance110 Ohms
    Cable Length6m
    Pins3
    Conductor Resistance130 Ohms/km
    Conductor Capacitance20 pF/m
    Capacity Inner Conduct. Shield/Inner Conduct.65 pF/m
    Wire Connection1.8 mm2
    Outer Cable Diametre6mm
    Outer Isolation TypePE
    Contact TypeSilver Plated
    1st ShieldBraided
    Shield Resistance12.5 Ohms/km
    Filler MaterialCotton
    Conductors2
    Conductor ConstructionStranded Core
    Maximum Ambient Temperature60 Degrees C
    Minimum Ambient Temperature-20 Degrees C
    IP RatingIP20
    MaterialCopper, PE
    ColourBlack
    Weight0.36kg
