- DAP DMX Lead, 5 pin XLR - 75 cm
DAP DMX Lead, 5 pin XLR - 75 cm
SKU:
FLX0875
DAP
The DAP FLX08 is a professional-grade 5-pin DMX/AES-EBU cable designed for reliable signal transmission over short distances. With a length of 0.75 metres, it’s ideal for linking DMX-controlled lighting or audio gear in tight or compact setups. Featuring 110-Ohm impedance, it ensures optimal transmission of digital AES/EBU signals, reducing interference and maintaining data integrity.
This DMX lead includes durable DAP connectors that support interchangeable colour rings for easy channel identification, streamlining setup and troubleshooting. A hook-and-loop fastener is included for neat cable management during transport and storage.
Compact, reliable, and built for performance, the DAP FLX08 0.75M is the perfect short-length DMX solution for professional lighting and audio setups.
reward points
- Product Features
110-Ohm impedance for accurate AES/EBU and DMX signal transmission
0.75 m cable length – ideal for short DMX links and patching
Professional 5-pin XLR connectors with colour ring support
Hook-and-loop fastener for convenient storage
Robust build quality for stage, studio, or touring use
- Technical Specification
Specification Connector 1 XLR 5 Pin Connector 2 XLR 5 Pin Impedance 110 Ohms Cable Length 0.75m Pins 5 Conductor Resistance 80 Ohms/km Capacity Inner Conduct. Shield/Inner Conduct. 64 pF/m Wire Connection 0.34 mm2 Outer Cable Diametre 7.5mm Outer Isolation Type PVC Contact Type Silver Plated 1st Shield Braided Tinned Copper 2nd Shield Aluminium Foil Shield Resistance 30 Ohms/km Filler Material Paper Conductors 4 Maximum Ambient Temperature 70 Degrees C Minimum Ambient Temperature -20 Degrees C IP Rating IP20 Material Copper, PVC Colour Black Weight 0.125kg
