Cloud 24-120EK 120 Watts RMS output @ 4 or 8 Ohm/70V-100V Digital amplifier

SKU: clo 24-120EK
Cloud Electronics

The 24-120 is a brand new approach to 2 Zone Mixer Amplification. Utilising the highest quality amplifier and digital?power supply technology.?The Cloud 24-120 is a two zone mixer-amplifier intended to provide a complete audio solution for Houses of Worship, retail outlets, hotels, licensed premises and other spaces where music,?announcements and/or flexible paging are required.
Catering for up to four music sources, it provides independent source and level control of music in each zone with microphone mixing as required, with full paging facilities. Each zone includes a mono power amplifier and the unit occupies only 1U of rack height.

?Two zone mixer/amplifier
2 x transformer-less Class-D 120W amplifiers with limiters on each zone plus Thermal/Short Protection
High-Impedance Power sharing (24-120 only)
4 Line inputs, 2x unbalanced/ 2x balanced
1 Mic input with analogue paging options
Integrated chime triggered by access control
100Hz dedicated high-pass filter on Microphone input
Phantom power selectable by internal jumper
Music level and source selection via RSL-4 & RSL-6
Facility input (Zone 1 or Both) for active modules LM-2/BT-1
RS232 control interface
Line 4 priority
Mic over Music input priority
Separate EQ for music and mic signals
2 x Auxiliary balanced line outputs
1 x Utility / Loop output with independent line & mic controls with music content selection
Remote Music Mute configurable for NO or NC operation
Selectable speaker output impedance (4/8/70v/100v)
Efficient, Universal Power Supply
Variable Speed Fan Cooling
