TOA A-3224DMZ A-3200 Series 240 Watt Digital Mixer Amplifier, MP3, Bluetooth, & 5 Zones

SKU: A-3224DMZ
TOA

TOA A-3224DMZ A-3200 Series 240 Watt Digital Mixer Amplifier, MP3, Bluetooth, & 5 Zones

A-3224DMZ is a high performance yet cost-effective mixer power amplifier equipped with MP3, Bluetooth function and Zone selection. Ideal for broadcasting, paging, or background music in schools, offices, shops, houses of worship and large ballrooms.

• High durability, high reliability and high performance.
• Four (Five microphone on A-324DME-AS) microphone inputs, two AUX inputs and one recording output.
• Speaker output of constant voltage distribution system (100V) & low impedance (4 :).
• Operates on AC power.
• Muting function.
• Independent input volume control and master volume control.
• Independent tone control of boost and cut type for both high and low frequency.
• MIC 1 equipped with phantom power for condenser microphone and also option for Chime Microphone.
• Current limiter circuitry protects transistor and thermal protection circuitry prevent a failure due to overheat.
• All MIC inputs are electronically-balanced input.
• Additional features such as built in MP3 Player, zone Selector and 5 Bands equalizer
• Power Source 100 - 240 V AC, 50/60Hz
• Rated Output  240 W
• Power Consumption  62 W (AC operation at 1/8 maximum output without clip)
• Frequency Response 50 - 20,000 Hz
• Muting MIC 1: Mutes other input signals by 0-30 dB attenuation
• Indicator: Power, Signal , Peak, Protect
• Ventilation: Fan Cooling
• Finish Panel: ABS resin, black
• Case: Steel plate, black
• Dimensions: 420 (W) ? 100.9 (H) ? 357 (D) mm
• Weight: 4.9 kg
• Accessory: Removable terminal plug (2 pins) x 5, Antenna FM radio (1m) x 1

Input

• MIC 1: 1 mV (-60 dB*), 600 , balanced, phone jack, selectable to RJ45
• MIC 2-3: 1 mV (-60 dB*), 600 , balanced, phone jack
• MIC 4: 1 mV (-60 dB*) 600 , balanced, phone jack, selectable to AUX 1
• AUX 1: 100 mV (-20 dB*), 10 k, unbalanced, RCA pin jack, selectable to MIC 4
• AUX 2: 100 mV (-20 dB*), 10 k, unbalanced, RCA pin jack
• MP3: LED Display, Support USB, SD/MMC card (up to 32GB), Bluetooth, Radio FM, Record

Output

• Speaker out: Speaker Output in screw type terminal
• Direct line (selectable): 42 (100 V) or 4
• Rec out: 0 dB*, 600 , unbalanced, RCA pin jack
• 5-zone selector (all zones simultaneously selectable)
• Phantom Power: DC +21 V (MIC 1)
• S/N Ratio: Over 60 dB
• Total Harmonic Distortion: Under 1% at 1 kHz, 1/3 rated power

Tone Control

• Bass: 10 dB at 100 Hz
• Treble: 10 dB at 10 kHz
