OPTICAL

• Light Source: 91 LEDs (18 red, 18 green, 19 blue, 18 amber, 18 lime green) 3 W, (722 mA), 6031 K, 50,000 hours life expectancy
• Colour Temperature (range): 2800 to 6500 K
• Colour Temperature (at full): 6031 K
• CRI (3200 K): 86
• Beam Angle (w/5 lens): 7
• Beam Angle (w/10 lens): 10
• Beam Angle (w/14 lens): 11
• Beam Angle (w/19 lens): 19
• Beam Angle (w/26 lens): 24
• Beam Angle (w/36 lens): 28
• Beam Angle (w/50 lens): 41
• Beam Angle (w/1530 lens)(Narrow): 13
• Beam Angle (w/1530 lens)(Wide): 24
• Beam Angle (w/2550 lens)(Narrow): 23
• Beam Angle (w/2550 lens)(Wide): 36
• Field Angle (w/5 lens): 7
• Field Angle (w/10 lens): 10
• Field Angle (w/14 lens): 14
• Field Angle (w/19 lens):19
• Field Angle (w/26 lens): 26
• Field Angle (w/36 lens): 34
• Field Angle (w/50 lens): 51
• Field Angle (w/1530 lens)(Narrow): 15
• Field Angle (w/1530 lens)(Wide): 29
• Field Angle (w/2550 lens)(Narrow): 26
• Field Angle (w/2550 lens)(Wide): 50
• Lumens (w/19 lens): 3,236
• Lumens (w/26 lens): 4,316
• Lumens (w/36 lens): 3,918
• Lumens (w/50 lens): 3,813
• Illuminance (w/5 lens): 16,300 lux @ 5 m
• Illuminance (w/10 lens): 7,430 lux @ 5 m
• Illuminance (w/14 lens): 4,420 lux @ 5 m
• Illuminance (w/19 lens): 2,530 lux @ 5 m
• Illuminance (w/26 lens): 1,720 lux @ 5 m
• Illuminance (w/36 lens): 1,020 lux @ 5 m
• Illuminance (w/50 lens): 457 lux @ 5 m
• Illuminance (w/1530 lens)(Narrow): 4,260 lux @ 5 m
• Illuminance (w/1530 lens)(Wide): 1,620 lux @ 5 m
• Illuminance (w/2550 lens)(Narrow): 1,790 lux @ 5 m
• Illuminance (w/2550 lens)(Wide): 825 lux @ 5 m
• Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25000Hz

DYNAMIC EFFECTS

• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Focus: Manual
• Strobe Rate: 0 to 28 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Built-in Automated Programs: Yes

CONSTRUCTION / PHYSICAL

• Dimensions (fixture only): 26 x 11.33 x 10.4 in (660 x 287.9 x 264.6 mm)
• Dimensions (w/5 lens extended): 47.04 x 14.17 x 14.48 in (1195 x 360 x 368 mm)
• Dimensions (w/10 lens extended): 38.3 x 12.16 x 12.48 in (973 x 309 x 317 mm)
• Dimensions (w/14 lens extended): 35.2 x 11.33 x 10.4 in (894.2 x 287.9 x 264.6 mm)
• Dimensions (w/26 lens extended): 32.37 x 11.33 x 10.4 in (822.3 x 287.9 x 264.6 mm)
• Dimensions (w/1530 lens): 38.6 x 11.33 x 10.4 in (980.6 x 287.9 x 264.6 mm)
• Dimensions (w/2550 lens): 31.3 x 11.33 x 10.4 in (795.1 x 287.9 x 264.6 mm)
• Weight (fixture only): 23.2 lb (10.5 kg)
• Weight (w/14 lens): 28.6 lb (12.9 kg)
• Weight (w/26 lens): 27.4 lb (12.4 kg)
• Weight (w/1530 lens): 35.8 lb (16.2 kg)
• Weight (w/2550 lens): 32.8 lb ( 14.8 kg)
• Exterior Color: Black
• Gobo Size (Optional): A?: 100 mm (outside), 75 mm (image), 2.5 mm (max. thickness)
• Gobo Size (Optional): B?: 86 mm (outside), 64.5 mm (image), 2.5 mm (max. thickness)
• Accessory Holder/Gel Frame Size (5 lens): 14 in (356 mm)
• Accessory Holder/Gel Frame Size (10 lens): 12 in (304 mm)
• Accessory Holder/Gel Frame Size (14 lens): 7.5 in (191 mm)
• Accessory Holder/Gel Frame Size (19, 26, 36, and 50 lens): 6.25 in (159 mm)
• Accessory Holder/Gel Frame Size (1530 lens): 7.5 in (191 mm)
• Accessory Holder/Gel Frame Size (2550 lens): 7.5 in (191 mm)

CONNECTIONS

• Power Connection: Edison (local) plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Data Connectors: 5-pin XLR
• Cable Length (power): 5 ft (1.5 m)

CONTROL

• Control Protocol: DMX, RDM
• DMX Channels: 1, 4, 6, 8, 11, 13, 14, 16 or HSV
• Modes/Personalities: 9 personalities (1, 4, 6, 8, 11, 13, 14, 16 or HSV)

ELECTRICAL

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 7 units @ 120 V; 11 units @ 208 V; 12 units @ 230 V
• Power and Current: 225 W, 1.88 A @ 120 V, 60 Hz
• Power and Current: 236 W, 1.14 A @ 208 V, 60 Hz
• Power and Current: 241 W, 1.05 A @ 230 V, 50 Hz

CERTIFICATIONS / QUALIFICATIONS

• CE, MET, FCC
• IP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valve
• Temperature (Ambient): -4 F to 113 F (-20 C to 45 C)
