Audio Technica ES947WC/XLR Cardioid Condenser 3-Pin Flush-Mount Boundary Microphone White

SKU: ES947WC/XLR

Please allow 3-5 working days for Delivery

Audio Technica

This low-profile cardioid condenser boundary microphone is recommended for unobtrusive table-, ceiling-, or panel-mount applications in high-quality sound reinforcement, professional recording and teleconferencing. Designed for permanent installation, the microphone is equipped with a self-contained power module with an XLRM-type output connector, eliminating the need for an external power module. Protected by a rugged all-metal case with a two-layer steel mesh grille, the microphone has a cardioid pattern for enhanced gain before feedback and improved signal-to-noise ratio.

Product Features

• Designed for surface-mount applications such as high-quality sound reinforcement, professional recording and teleconferencing
• Low-profile element provides uniform cardioid polar pattern with 120,, acceptance angle
• Mounts unobtrusively in table-tops, ceilings and wall panels
• Self-contained power module with XLRM-type output connector
• Rugged all-metal case with a two-layer steel mesh grille
• Isolators provide mechanical dampening of mounting-surface vibration
• Requires 11V to 52V DC phantom power
• UniGuard,, RFI-shielding technology offers outstanding rejection of radio frequency interference (RFI)

Product Specifications

General

• ELEMENT: Fixed-charge back plate, permanently polarized condenser
• POLAR PATTERN: Half-cardioid (Cardioid in hemisphere above mounting surface)
• FREQUENCY RESPONSE: 40-12,000 Hz
• OPEN CIRCUIT SENSITIVITY: -42 dB (7.9 mV) re 1V at 1 Pa
• IMPEDANCE: 200 ohms
• MAXIMUM INPUT SOUND LEVEL: 142 dB SPL, 1 kHz at 1% T.H.D.
• DYNAMIC RANGE (typical): 113 dB, 1 kHz at Max SPL
• SIGNAL-TO-NOISE RATIO: 65 dB, 1 kHz at 1 Pa
• PHANTOM POWER REQUIREMENTS: 11-52V DC, 2 mA typical
• OUTPUT CONNECTOR: Integral 3-pin XLRM-type

Physical & Dimensions

• Length: 69mm
• Diameter: 30mm
• Weight: 64g
