Sennheiser MEB 104-L B Boundary microphone, built-in, cardioid

SKU: sen 505609
Sennheiser

Sennheiser MEB 104-L B Boundary microphone, built-in, cardioid, 5-pin XLR-M, 24-48 V phantom power, with illuminated ring, black

Compact and unobtrusively designed, the cardioid boundary layer microphone MEB 104 (cardioid) fits any style of interior and can be easily installed into surfaces such as tables or ceiling tiles. It features a proven Sennheiser microphone capsule for the best speech intelligibility, and is protected by a rugged housing. Its -L variant features a bi-colour LED ring for status indication.

• Safe and strong housing
• Can be installed in various ways
• Features a bi-colour LED?ring for status indication
• Unobtrusive, timeless design
• Discreet look and design
• Finish:?Black

General

• Connector:
  • MEB 104:? XLR-3
  • MEB 104-L:? XLR-5
• Current consumption:
  • MEB 104: ?3 mA
  • MEB 104-L: ?6 mA
• Frequency response: ?40 Hz - 20 kHz
• Max. sound pressure level: ?125 dB
• Transducer principle:? pre-polarized condenser microphone
• Pick-up pattern: ?cardioid
• Nominal impedance: ?200 ohm
• Phantom powering: ?P 24 - P 48
• Operating temperature: ?0 - +40 C
• Equivalent noise level: ?28 dB (A)
• Equivalent noise level weighted as per CCIR:? 468-3 38 dB (CCIR)
• Acoustics:? Boundary Layer Microphone
• Dynamic range:? 97 dB (A)
• Sensitivity:? 14 mV/Pa
• Thread:? M 20

Physical & Dimensions

• Weight:? 60 g
• Dimensions
• Height:? 90 mm (19 mm above surface)
• Diameter:? 28.5 mm
• Colour:? Black
