Wharfedale DELTA F18B Passive Subwoofer, 800w Continuous

Wharfedale DELTA F18B Passive Subwoofer, 800w Continuous - Wharfedale

Name: Wharfedale DELTA F18B Passive Subwoofer, 800w Continuous
Brand: Wharfedale
SKU: WP-088301-00B
Price: 797.052 GBP
Availability: InStock

roll over the image to zoom in

Wharfedale DELTA F18B Passive Subwoofer, 800w Continuous
SKU: WP-088301-00B
Wharfedale

Wharfedale DELTA-F18B Passive Subwoofer

Delta F18B is supplied with castors so is a surprisingly portable and easily moveable enclosure.Â Where significant extension of low frequency output of a sound system is required over middle-long distances the addition of one or more Delta F18B subwoofers will provide high output low frequency enhancement to the overall sound system.

The folded horn design enables the Delta F18B to deliver ground shaking low frequencies over long distances (Unlike direct radiating designs which provide near to middle distance sound).

The Delta F18B is designed to work with an external, active crossover unit.Â

Model Name	Delta F18B
System Type	Passive
Configuration	Folded horn subwoofer
Frequency Response (+/-3 dB)	30 Hz , 300 Hz
Frequency Range (-10 dB)	Â
Sensitivity (2.83 v / 1 m)	106 dB
Calculated Maximum SPL @1 m	141 dB
System Rated Impedance	8
Low Frequency Transducer	Â
Size	470 mm / 18,
Voice Coil Size	102 mm / 4,
Rated Impedance	8
LF Power (re:AES2-2012)	800 w
Power	Â
System Continuous Power	800 w
System Programme Power	1600 w
System Peak Power	3200 w
Crossover frequency	Â
Input Connector	2 x NL4 (speakON Compatible)
Hardware	Â
Pole Mount	35 mm
Handles	4 on Sides
Enclosure	Â
Enclosure Material	18 mm Plywood
Finish	Rhino Rock
Grille Material & Finish	Â
Dimensions , Unpacked	Â
Height	914 mm / 36.0,?
Width Front	609.6 mm / 24.0,?
Width Rear	609.6 mm / 24.0,?
Depth	914 mm / 36.0,?
Dimensions , Packed	Â
Height	1009 mm / 39.72,?
Width Front	689 mm / 27.12,?
Width Rear	689 mm / 27.12,?
Depth	994 mm / 39.13,?
Weight	Â
Net Weight (kg / lbs)	80.5 kg / 177.1 lbs
Gross Weight (kg / lbs)	85.2 kg / 187.44 lbs
