TOA YW-4500 UHF Wireless Antenna

SKU: YW-4500
TOA

The wireless antenna YW-4500 has been designed for UHF band wireless system. Cable loss can be compensated for by a built-in RF signal booster. The YW-4500 in a dipole antenna designed to be installed in doors. Use the coaxial cable with 75 impedance.

• Omnidirectional dipole antenna for wall or ceiling mounting
• By means of the integrated RF amplifier losses induced by long cable runs can be compensated
• Dipole Ratio Relative Gain: 8dB or more
• 75 Output impedance
• Receiving Frequency: 550 - 932 MHz
• Finish: White
• Power Source: ?7 - 12 V DC (supplied from amplifier or tuner)
• Current Consumption: ?15 mA or less
• Receiving Frequency: ?550 - 932 MHz, UHF
• Dipole Ratio Relative Gain: ?8 dB or more (780 MHz)
• VSWR: ?3.0 or less
• Output Impedance: ?75
• Mounting Hole Pitch: ?83.5 mm (dimensions for wiring box)
• Operating Temperature: ?-10 %%dC to +50 %%dC
• Operating Humidity: ?30 % to 85 %RH (no condensation)
• Finish: ?AES resin, off-white
• Dimensions: ?105 (W) ? 140 (H) ? 126 (D) mm
• Weight: ?270 g
• Accessory:?
  • M3.5 screw for wiring box x 2
  • Tapping screw (M4) for wooden wall x 2
  • RG-6/U or RG-11/U sleeve x 1
