TOA VX-3308WM VX-3000 Series Wall Mount System, complete with 2 x VX-030DA amplifiers pre-installed

TOA VX-3308WM VX-3000 Series Wall Mount System, complete with 2 x VX-030DA amplifiers pre-installed - TOA

Name: TOA VX-3308WM VX-3000 Series Wall Mount System, complete with 2 x VX-030DA amplifiers pre-installed
Brand: TOA
SKU: VX-3308WM
Price: 6690.6 GBP
Availability: InStock

roll over the image to zoom in

TOA VX-3308WM VX-3000 Series Wall Mount System, complete with 2 x VX-030DA amplifiers pre-installed
SKU: VX-3308WM
TOA

TOA VX-3308WM VX-3000 Series Wall Mount System, complete with 2 x VX-030DA amplifiers pre-installed

Complete PA and VA system in one unit, including power supply and power amplifiers
Compact, flat unit that can be mounted in narrow environment (e.g. corridor)
Cost and time effective: all components and two 300 Watt amplifier modules pre-assembled and connected
One optional amp can be added
All indications and controls according to EN 54-16
Fault status indication for each speaker line
Operation and audio signal status indication per amplifier
8 control outputs by open-collector-transistor and 4 by 5 A relays
16 standard and 2 voltage-controlled control inputs with monitoring
IP network-based, max 160 units can be combined
Fully compatible with the (rack-mounted) VX-3000 system

Power / current consumption	1100 watts (at rated output incl. charging), 460 watts (EN 60065)
Frequency response	40 Hz - 20 kHz
Audio input	4 balanced audio inputs, sensitivity -20 dBV (line)/-60 dBV (mic), impedance: 47 kohms, phantom power 24 V selectable by software. 2 remote microphone inputs for up to 8 units.
Audio output	8 speaker lines isolated from earth
Control input	16 (contact), 2 (voltage controlled), all with surveillance
Control output	8 (open collector, no-voltage make contact, control current max. 10 mA, withstand voltage 28 V DC, on RJ45 jack). 4 (no-voltage make contact, relay contact (NC, NO, C), control current: 2 mA to 5 A, withstand voltage: 125 V AC, 40 V DC, Connector: removable terminal block (12 pins)
Operating temperature	-5 C to +45 C (23 F to 113 F)
Finish	Steel plate, black (RAL 9011 or equivalent)
Dimensions	550 x 700 x 200 mm (W x H x D)
Weight	33.1 kg
Power source	220 - 230 V AC, 50 / 60 Hz Battery 2x 12 V
Distortion	1 % (at 1 kHz)
Current consumption (value)	25 A from battery max.
S/N ratio	60 dBA (or better, at DA control link)
Indicator	AC Power in (green) ?1, Run (green) ?1, Emergency (red) ?1, CPU Off (red) ?1, LAN A (green) ?1, LAN B (green) ?1, RS Link A (green) ?1, RS Link B (green) ?1. Fault Status (yellow): General ?1, Unit ?1, Network ?1, EMG Mic ?1, Fuse ?1, Power ?1, CPU ?1, Zone ?8. Amplifier: Peak (red) ?3, Signal (green) ?3, Operate (green) ?3, Power (green) ?3. Battery (green): Charging ?1, Battery power ?1, connection ?1, condition ?1
Connection	AC-mains: 2 pin screw terminal at breaker, 1 screw terminal for earth Speaker outputs: 6-pin removable screw terminal block ?4 Control inputs: 9-pin removable screw terminal blocks ?3 Emergency control inputs: 5-pin removable screw terminal block ?1 Control outputs: 9-pin removable screw terminal block ?1, 12-pin removable screw terminal block ?1 Network: 9-pin removable screw terminal block ?2 Internal connections: DC power supply (max. 25 A): 2-pin screw terminal ?1 DC power supply 24 V DC, 0.3 A: 4-pin removable screw terminal block ?1
Current consumption	25 A from battery max.
