TOA PJ-154BS 15W, Projection Speaker, BS5839-8/EN54-24

SKU: PJ-154BS
TOA

The PJ-154BS is the voice alarm certification product. 2 way speaker system is suitable for announcement and music use in wide frequency range. Stylish and outstanding design inspired by the finest lighting fixtures. A supplied swivel bracket accessory allows for flexible speaker angle adjustment.

• Stylish and outstanding design inspired by the finest lighting fixtures
• Well balanced frequency response
• Supplied swivel bracket allows flexible speaker angle adjustment
• Easy impedance setting by rotary switch
• Paintable
• Certified according to EN 54-24, ISO 7240-24
• Compliant with BS-5839-8
• Frequency response: ?70 Hz - 20 kHz
• Connection: ?Ceramic screw terminals, thermal fuse in external connection box
• Sensitivity (1W, 1m):?
  • 91 dB (500 Hz - 5 kHz, pink noise)
  • 87 dB (1 W, 1 m at 100 Hz to 10 kHz pink noise)
  • 75 dB (1 W, 4 m at 100 Hz to 10 kHz pink noise)
• Maximum sound pressure level (1 m) (value): ?99 dB
• Speaker component: ?Low: 5 cone-type, High: 1 balanced dome tweeter
• Rated input (High Impedance): ?15 W (100 V), 7.5 W (70 V)
• Tappings
  • 100 V : 670 (15 W) / 1 k (10 W) / 2 k (5 W)
  • 70 V : 670 (7.5 W)/ 1 k (5 W)/ 2 k (2.5 W)
• Operating temperature: ?-10 C to +50 C ( 14 F to 122 F)
• Finish: ?HIPS resin, off-white (RAL 9010 or equivalent), Grille: Surface-treated steel plate net, off-white (RAL 9010 or equivalent color), paint
• Dimensions: ?186 x 251 mm ( x H)
• Weight: ?2.1 kg
