TOA PJ-100W Projection Speaker, 10W (100v), 65 - 18KHz, Off-white

SKU: PJ-100W
TOA

The PJ-100W and PJ-200W Projection Speakers are designed for indoor use. The built-in terminal board provides an easy cable connection and allows bridge wiring. Its wide frequency range makes it suitable for use in both paging and BGM applications.

• Wide range speaker
• Ideally suited for Information broadcast
• Maximum input: 15 W (PJ-100W)
• Built-in transformer for 50 V, 70 V and 100 V speaker line.
• Two grommets for parallel (bridge) connection.

Applications

• Railway stations
• Parking garages
• Industrial facilities

• Frequency response: ?65 Hz - 15 kHz
• Sensitivity (1W, 1m): ?92 dB (at 1 kHz)
• Speaker component: ?12 cm
• Rated input (High Impedance): ?10 W
• Tappings
  • 100 V: 1 k,? (10 W) / 2 k,? (5 W) / 4 k,? (2.5 W)
  • 70 V: 500 ,? (10 W) / 1 k,? (5 W) / 2 k,? (2.5 W) / 4 k,? (1.25 W)
  • 50 V: 250 ,? (10 W) / 500 ,? (5 W) / 1 k,? (2.5 W) / 2 k,? (1.25 W) / 4 k,? (0.63 W)

Physical

• Dimensions (W x H x D) 160 x 200 x 195 mm
• Dimensions ( x D) x 195 mm
• Finish ABS resin, off-white (RAL 9010 or equivalent)
