TOA PC-1860BS 6W, Ceiling Speaker, BS5839-8 / EN54-24

SKU: PC-1860BS
TOA

TOA PC-1860BS 6W, Ceiling Speaker, BS5839-8 / EN54-24

The PC-1860BS is equipped with a fire dome to protect it from fire and to prevent fire from spreading through the ceiling. Thus, the speaker is designed according to British Standard BS 5839-8: 2008 and EN54-24.

• Flat front panel
• Quick and easy installation
• Fire dome made of steel
• Ceramic screw terminal block and thermal fuse
• 6 W rated input
• 12 cm speaker

Applications

• Educational facilities
• Hospitals / Health Care
• Hotels
• Public Buildings
• Retail stores
• Shopping centers

General

• Frequency response: 170 Hz - 20 kHz (peak -20 dB)
• Connection: 2-Steatite connector (3 pole)
• Sensitivity: (1W, 1m) 95 dB (500 Hz - 5 kHz, pink noise)
• Speaker component: 12 cm cone-type
• Rated input (High Impedance): 6 W (100 V), 3 W (70 V)
• Tappings
  • 100 V: 1.7 k (6 W) / 3.3 k (3 W) / 6.7 k (1.5 W) / 13 k (0.8 W)
  • 70 V: 1.7 k (3 W) / 3.3 k (1.5 W) / 6.7 k (0.8 W) / 13 k (0.4 W)

Physical

• Mounting hole: 156 mm
• Dimensions ( x D) 180 x 105 mm
• Finish: Steel plate, paint, traffic white (RAL 9016 or equivalent)
• Grille: Steel net, paint, white (RAL 9016 or equivalent)
• Operating temperature: -10 C to +50 C
