TOA N-8000MS N-8000 Series Master Station c/w LCD Display & Handset

SKU: N-8000MS
TOA

This Master Station is designed to connect to the IP Intercom Exchange and provide hands-free or handset conversation of high sound quality. In addition to the functions of the standard Master Station, the Multifunctional Master Station provides LCD display, Auto-dialer function enabling one-touch dialling, headset terminal and external speaker terminal. This station can be mounted to the wall using an optional YC-280 wall mounting bracket.

• Paging and Communication function
• With LC-Display
• Hands-free or handset conversation
• Auto-dialer function
• Headset terminal
• External speaker terminal
• Power Source: ?48 V DC (supplied from the IP intercom exchange (option))
• Power Consumption: ?1.8 W (at rated), 2.4 W (max.)
• Wiring Method: ?1 set of twisted pair cable
• Transmission System: ?2 wire 160 kbps echo canceller transmission system
• Signal Level: ?Under 0 dB*
• Speech Method: ?Hands-free or handset conversation
• Audio Frequency Range: ?300 Hz - 7 kHz
• Transmission Range: ?Max. 1500 m (0.65 mm, Loop resistance 170 )
• Hands-free:
  • Speaker: 5.7 cm cone-type, 0.6 W, 8
  • Microphone: Omni-directional electret condenser microphone
• Handset:
  • Receive path: Dynamic type
  • Send path: Electret condenser microphone
• Display: ?LCD: Alphanumeric characters (16 characters ? 2 lines)
• Indication: ?Status lamp
• Line Connecting Terminal: ?RJ11 modular jack
• Headset Terminal: ?Speaker: 3 mW, 32 , Microphone: -49 dB*, 3.5 mm mini Jack
• External Speaker Terminal: ?0.6 W, 8 , screwless connector (2 pins)
• Installation Method: ?Desk/Surface mounted master station (When mounting to the wall, use the optional YC-280.)
• Operating Temperature: ?0 , to +40 ,
• Operating Humidity: ?Under 90 % RH (no condensation)
• Finish: ?Body, Handset: ABS resin, grey
• Dimensions: ?148 (W) x 208 (H) x 70.5 (D) mm (excluding a curl cord section)
• Weight: ?800 g
• Accessory: ?Connection cord (3 m) ?1
• Option: ?Wall mounting bracket: YC-280
