TOA HS-120W Coaxial Array Speaker, 100W (8Ω), 12", 80 - 20KHz, White

SKU: HS-120W
TOA

One of the most difficult speaker requirements to satisfy is a cost-effective mid-size speaker system that offers high quality sound no matter what the application. TOA HS-Series speakers are equipped with narrow-directivity control (90 horizontal ? 40 vertical). This useful feature allows tailoring the speaker's dispersion characteristics to better suit the acoustic environment in which it is installed. The versatile HS-Series is compatible for use with 100V/70V lines for distributed applications. The HS-Series speakers are exceptional in offering useful features at an attractive price.

• 12 LF speaker
• Well-controlled sound coverage: 90 horizontal x 40 vertical
• Easy to carry and easy to install, with handle for easy transportability
• Low impedance version
• Twin input terminal connections (Speakon and screw terminals) for fixed and mobile installation
• Size and weight have been reduced thanks to the use of the array tweeter
• Can be used as a floor monitor

General

• Enclosure: Sealed type
• Power Handling Capacity: Continuous pink noise: 100 W. Continuous program: 300 W
• Rated Impedance: 8
• Sensitivity: 97 dB (1 W, 1 m)
• Frequency Response: 80 - 20,000 Hz
• Crossover Frequency: 3 kHz
• Directivity Angle: Horizontal: 90,, Vertical: 40,
• Speaker Component: Low frequency: 30 cm (12) cone-type. High frequency: Balanced dome tweeter ? 6
• Input Terminal: NEUTRIK NL4MP Speakon and M4 screw terminal, distance between barriers: 9 mm (0.35)
• Operating Temperature: -10, to +50, (14,F to 122,F)

Physical & Dimensions

• Finish: Enclosure: Polypropylene, black. Punched net: Surface-treated steel plate, white
• Dimensions: 361 (W) ? 448 (H) ? 320 (D) mm (14.21 ? 17.64 ? 12.6)
• Weight: 8.5 kg (18.74 lb)
