TOA F-1522SC Wide Dispersion Ceiling Speaker, 6W (8Ω/100v), Full Range, with Dust Bag

SKU: F-1522SC
TOA

TOA introduces a new range of ceiling-mounted speakers that have been designed and engineered to overcome limiting factors that have been associated with conventional ceiling-mount speakers. Most noticeable has always been the high-frequency roll-off that resulted from limited speaker dispersion characteristics. TOA's new ceiling speaker range provides well-balanced audio reproduction without treble attenuation over an expanded listening area thanks to the extra-wide dispersion characteristics that are part of the overall speaker design. Perceived speaker directionality and beaming tendencies are minimized, resulting in a natural, well-balanced sound over a wide area at all levels. Conventional speakers exhibit high frequency roll-off characteristics as the distance between speaker and listener increases. However TOA believes that an ideal ceiling-mounted speaker's response characteristics should include wide dispersion and non-frequency dependent directionality and this new ceiling speaker series proves that.

• Designed to blend into ceilings with a smooth, low-profile design.
• Extra ease of use and higher cost-effectiveness with the metal back can enclosure for the speaker rear.
• Minimal high frequency roll-off allows clear and well-balanced sound reproduction over a wide listening area.
• Quick and easy installation to precisely mount speaker onto ceilings and walls. Rotating front grille also installs quickly and conveniently.
• The Electronic Controller (AC-120) option is required to provide increased control of the F-122C's speaker response.

General

• Rated Input: 6W (high impedance)
• Power Handling Capacity: Continuous pink noise: 9W(8), 6W (16). Continuous program: 18W (8), 12W(16)
• Impedance (100V Line): 1.7k (6W), 3.3k (3W)
• Impedance (70V Line): 830 (6W), 1.7k (3W), 3.3k (1.5W)
• Impedance (25V Line): 830 (0.75W), 1.7k (0.4W), 3.3k (0.2W)
• Low (Adjustable): 16, 8
• Sound Pressure Level: 88dB (1W, 1m)
• Frequency Response: 65 - 18,000Hz (-10dB), 45 - 20,000Hz (-20dB) at installation in 1/2 free sound field (measured by installing the unit in the center of a ceiling.)
• Speaker Component: High frequency: 10cm cone- type
• Speaker Component: Low frequency: 10cm cone- type
• Mounting Hole: 135mm(maximum ceiling thickness: 37mm)
• Input Terminal: Push-in connector (Bridging terminal-2 branch type)
• Usable Cable: 600V Vinyl-insulated cable (IV wire or HIV wire), Solid copper wire; 0.8 - 1.6mm (equivalent to AWG No.20 - 15), 7-core twisted copper wire:0.75 - 1.25mm (equivalent to AWG No.18 - 17)
• Baffle: Fire-resistant ABS resin (resin material grade; UL-94 V-0 or its equivalent), black
• Rim: Fire-resistant ABS resin (resin material grade; UL-94 V-0 or its equivalent), white, paint

Physical & Dimensions

• Dimensions: 155 x 117 (D)mm
• Weight: 1kg (including panel)
