TOA D-971R D-900 Series 4 Channel Line Output Module (RCA)

SKU: D-971R
TOA

The D-971R is a 4-channel line output module designed for use with the D-901 Digital Mixer, etc. It is equipped with standard RCA pin jacks.

• 4-channel, RCA pin jack
• D/A converter: 24 bit
• Distortion: 0.05 % or less
• Frequency response: ?20 Hz - 20 kHz (1 dB)
• Distortion: ?< 0.05 %
• Outputs: ?4 channels (2 outputs for each channel), -10dBu, > 600 Ohm, Connector: RCA pin jack
• A/D, D/A Converter: ?24 bit
• Sampling frequency: ?48 kHz
• Dimensions (W x H x D): ?35 x 119,5 x 178,4 mm
• Dimensions ( x D); ?x 178,4 mm
• Finish: ?Steel plate, pre-coated, 30% gloss, black,
