TOA D-922E D-900 Series 2 Channel Mic/Line Input Module (Term Block)

SKU: D-922E
TOA

The D-922E is a 2-channel microphone/line input module designed for use with the D-901 Digital Mixer, etc. It is equipped with removable terminal block type connectors. The D-901's 4-pole DIP switch is used to set the input sensitivity, phantom power supply, and ground lifting.

• 2-channel microphone/line input module
• Equipped with removable terminal block type connectors
• Frequency response: ?20 Hz - 20 kHz (1 dB (+4 dB Input)
• Distortion: ?< 0.2 % (+4 dBV input)
• Inputs: ?2 channels, -50/-36/-10/+4 dBu, (selectable with the DIP switch), 4.7kOhm, electronically-balanced, Connectors: removable terminal block (3 pins), Phantom power supply (12-15V DC),, Ground lift switch
• A/D, D/A Converter: ?20 bit
• Sampling frequency: ?48 kHz
• Dimensions (W x H x D): ?35 x 119,5 x 178,4 mm
• Dimensions ( x D): ?x 178,4 mm
• Finish: ?Steel plate, pre-coated, 30% gloss, black,
