TOA CA-160 Mobile Amplifier, 60 watt

SKU: CA-160
TOA

The CA-160 is a 1-DIN size unit 60 W car amplifier designed for use with a 12 V battery car. Fits in standard car radio compartment, 2 microphone inputs, 1 AUX input, level control for microphones, all controls on the front, including hand-held microphone with integrated talk button.

• Mobile amplifier for easy installation in vehicles
• DC operation from 12 V battery
• Rated output 60 W
• 2 MIC inputs
• AUX input for CD player, radio, etc.
• Unidirectional dynamic microphone with talk switch
• Front pause function
• DIN size, easy in-dash installation
• Rugged construction

General

• Power source: 14 V DC (10 - 16 V DC)
• Rated output: 60 W
• Frequency response: 100 Hz - 10 kHz (3 dB)
• Distortion: < 5 % (at 1 kHz)
• Power consumption: < 9 A
• Inputs: MIC 1,2: 600 , 4 mV, phone jack
• AUX: 10 k, 500 mV, phone jack terminal
• Outputs: 4 / 8

Physical & Dimensions

• Finish: ABS resin, Steel plate, black
• Dimensions (W x H x D): 178 x 50 x 170 mm
• Weight: 1.2 kg
• Accessory (included): Dynamic microphone (with talk switch) 1, microphone holder 1, mounting screw (4 x 16) 2, mounting bracket 1, mounting screws hexagon bolt (M5x15) 2, screw (M4x8) 4, nut (M5) 2, spring washer (M5) 2, spring washer (M4) 4, plain washer (M5) 4, plain washer (M4) 4,
• power cord (1.5 m) 1, speaker cable (0.3 m) 1, fuse (CA-115: 4 A / CA-130: 8 A / CA-160: 12 A) 1
•
