TOA AT-4030B Q-EB Attenuator AT-4000 Series 30W with Box

SKU: AT-4030B Q-EB
TOA

Designed with ergonomics of the human hand in mind, AT-4000 Series Attenuators control knob comes in a size that provides comfortable grip and excellent control with every turn. Consisting of 8 steps attenuation, the series is built to provide precision volume control with a difference of 3dB in every step. The built-in overriding relay feature allows emergency paging which is indicated by the LED light when activated.

• Surface or flush mount
• Glossy finish in white
• Clip-on face plate
• Terminal block for thicker diameter cable
• Ergonomic control knob with better grip for easy turn
• 8-step attenuation level control

General

• Input Capacity: 30 watt
• Attenuation: 8 Steps ( 0dB, -3dB, -9dB, -12dB, -15dB, -18dB, OFF )
• Override Indicator Red LED (4-wire connection only)
• Overriding Voltage 24V, 11mA DC (4-wire connection only)
• Terminal: Screw type x 5 (Terminal)
• Usable Cable: Cable range 22 - 14 AWG
• Accessories: Black Box 85.5 (W) x 85.5 (H) x 60 (D) mm
• Plate mounting screw 2

Physical & Dimensions

• Dimensions: 86 (W) x 86 (H) x 51 (D) mm
• Weight: 0.45 kg
• Color: White (RAL 9016 or equivalent)
• Finish: Knob, Cover Panel: ABS Resin, White (RAL 9016 or equivalent)
• Finish: Front Panel (Plate): Surface treated steel plate
