Sennheiser SKM 100 G4-S Handheld transmitter with mute s - Sennheiser
roll over the image to zoom in
Sennheiser SKM 100 G4-S Handheld transmitter with mute s
SKU:
Sennheiser
Sennheiser SKM 100 G4-S-1G8 Handheld transmitter with mute switch. Microphone capsule not included, frequency range: 1G8 (1785 - 1800 MHz)
Powerful handheld transmitter with a lightweight aluminum housing and integrated mute switch for evolution wireless G4 100 Series systems.
?
Your choice of Sennheiser,s renowned e 835, e 845, e 865, e 935, e 945 capsules
Easy and flexible wireless synchronization between transmitter and receiver via infrared
Fast frequency allocation for up to 12 receivers via new linking functionality
Up to 20 compatible channels
Up to 42 MHz bandwidth with 1680 selectable frequencies, fully tunable in a stable UHF range
Transmission Range: up to 100 meters / 300 feet
High RF output power (up to 30 mW) depending on country regulations
- Frequency range
- 1G8: 1785 - 1800 MHz
- Dimensions
- Approx. 50 x 265 mm
- Compander
- Sennheiser HDX
- THD, total harmonic distortion
- 0.9 %
- Weight
- (incl. batteries) approx. 450 g
- Signal-to-noise ratio
- ? 110 dBA
- RF output power
- Max. 30 mW
- Switching bandwidth
- up to 42 MHz
- Peak deviation
- ,48 kHz
- Nominal deviation
- ,24 kHz
- Operating time
- Typically 8 h
- Modulation
- Wideband FM
- Power supply
- 2 AA batteries, 1.5 V or BA 2015 accupack
- Current consumption
- at nominal voltage: typ. 180 mAwith transmitter switched off: 25 A
- Input impedance
- 40 k
- Max. Input voltage
- 3 Veff
- Powering
- 3 V battery / 2.4 V rechargeable battery
- Transmission frequency
- Max. 1680 transmitting frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels
- AF frequency response
- 80 , 18,000 Hz
- Temperature Range
- -10 ,C to +55 ,C
- Frequency stability
- ,15 ppm
What's in the Box
- SKM 100 G4-S handheld transmitter
- MZQ 1 microphone clamp
- 2 AA batteries
- quick guide
- safety guide
- manufacturer declaration sheet
