Sennheiser EW300 G4-ME2-RC-GBW Wireless Lapel set

Sennheiser EW300 G4-ME2-RC-GBW Wireless Lapel set - Sennheiser

Name: Sennheiser EW300 G4-ME2-RC-GBW Wireless Lapel set
Brand: Sennheiser
SKU: sen 509932
Price: 1057.32 GBP
Availability: InStock

roll over the image to zoom in

Sennheiser EW300 G4-ME2-RC-GBW Wireless Lapel set
SKU: sen 509932
Sennheiser

Sennheiser ew 300 G4-ME2-RC-GBW Wireless lavalier set. Includes (1) SK 300 G4-RC bodypack transmitter, (1) ME 2-II lavalier microphone (omnidirectional, condenser), (1) EM 300-500 G4 rackmount receiver and (1) GA3 rack kit, frequency range:GBW (606 - 678 MHz)

Best choice for your business, top of the class in education. The G4 300 Series uses the power of an increased switching bandwidth of up to 88 MHz. New frequency ranges allow to operate multi-channel setups with dozens of channels while securing reliable operation - despite digital dividend.
The powerful clip-on mic package. Easy to operate, reliable while transmitting , G4 does the job. The 300 series lavalier mic set ensures hands-free operation even during the longest congress or lecture. Remote mute switch available for the bodypack transmitter.

Easy to use, fast setup time
Integrated network port allows control, monitoring and setup via Sennheiser Control Cockpit and WSM Software
Broad range of products and existing accessories (such as microphones) allows usage in any kind of environment
Up to 88 MHz bandwidth, up to 32 channels
Increased RF output power (10/30/50 mW)
Transmission Range: up to 100 meters / 330 feet
Compatible with wireless speaker system LSP 500 PRO
RC (remote control) switch available for the bodypack transmitter

EM 300-500 G4

Frequency range
GBw: 606 - 678 MHz
Dimensions
Approx. 202 x 212 x 43 mm
Compander
Sennheiser HDX
THD, total harmonic distortion
?0.9 %
Weight
Approx. 980 g
Audio output
6.3 mm jack socket (unbalanced): +12 dBu
XLR socket (balanced): +18 dBu
Signal-to-noise ratio
?115 dBA
Switching bandwidth
up to 88 MHz
Peak deviation
48 kHz
Nominal deviation
24 kHz
Modulation
Wideband FM
Power supply
12 V DC
Antenna connector
2 BNC sockets
Current consumption
350 mA
Adjacent channel rejection
Typically 75 dB
Intermodulation attenuation
Typically ?70 dB
Receiving frequency
Max. 3520 receiving frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels
RF sensitivity
< 2.5 V for 52 dBA eff S/N
Squelch
5 to 25 dBV in steps of 2 dB
Equalizer
Preset 1: Flat
Preset 2: Low Cut (-3 dB at 180 Hz)
Preset 3: Low Cut/High Boost (-3 dB at 180 Hz, +6 dB at 10 kHz)
Preset 4: High Boost (+6 dB at 10 kHz)
Temperature Range
-10 ?C to +55 ?C
Receiver Principle
True diversity
Blocking
75 dB

SK 300 G4

Dimensions
Approx. 82 x 64 x 24 mm
Compander
Sennheiser HDX
THD, total harmonic distortion
?0.9 %
Weight
(incl. batteries) approx. 160 g
Signal-to-noise ratio
115 dBA
RF output power
switchable: Low: typ. 10 mW, Standard: typ. 30 mW, High: typ. 50 mW
Switching bandwidth
up to 88 MHz
Peak deviation
48 kHz
Nominal deviation
24 kHz
Operating time
Typically 8 h
Modulation
Wideband FM
Power supply
2 AA batteries, 1.5 V or BA 2015 accupack
Current consumption
at nominal voltage: typ. 180 mA
with transmitter switched off: ?A
Input impedance
40 k, unbalanced / 1 M
Max. Input voltage
3 Veff
Powering
3 V battery / 2.4 V rechargeable battery
Transmission frequency
Max. 3520 frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels
AF frequency response
Mic: 80 ?18,000 Hz, Line: 25 ?18,000 Hz
Temperature Range
-10 ?C to +55?C
Frequency stability
15 ppm
