Sennheiser EW300 G4-BASE SKM-S-GBW Wireless Hand Held base System

SKU: sen 509994
Sennheiser

Sennheiser ew 300 G4-BASE SKM-S-GBW Wireless handheld base set. Includes (1) SKM 300 G4-S handheld microphone with mute switch (microphone capsule sold separately) (1) EM 300-500 G4 rackmount receiver, (1) GA3 rack kit, and (1) mic clip, frequency range:GBW (606 - 678 MHz)

Best choice for your business, top of the class in education. The G4 300 Series uses the power of an increased switching bandwidth of up to 88 MHz. New frequency ranges allow to operate multi-channel setups with dozens of channels while securing reliable operation - despite digital dividend.
The best choice if you need a handheld transmitter and maximum flexibility. This base set consists of the stationary receiver as well as a handheld transmitter. Just add your favorite capsule.

• Easy to use, fast setup time

• Integrated network port allows control, monitoring and setup via Sennheiser Control Cockpit and WSM Software

• Broad range of products and existing accessories (such as microphones) allows usage in any kind of environment

• Up to 88 MHz bandwidth, up to 32 channels

• Increased RF output power (10/30/50 mW)

• Transmission Range: up to 100 meters / 330 feet

• Compatible with wireless speaker system LSP 500 PRO

• RC (remote control) switch available for the bodypack transmitter

• Frequency range

  GBw: 606 - 678 MHz

• Dimensions

  Approx. 202 x 212 x 43 mm

• Compander

  Sennheiser HDX

• THD, total harmonic distortion

  0.9 %

• Weight

  Approx. 980 g

• Audio output

  6.3 mm jack socket (unbalanced): +12 dBu

  XLR socket (balanced): +18 dBu

• Signal-to-noise ratio

  ? 115 dBA

• Switching bandwidth

  up to 88 MHz

• Peak deviation

  ,48 kHz

• Nominal deviation

  ,24 kHz

• Modulation

  Wideband FM

• Power supply

  12 V DC

• Antenna connector

  2 BNC sockets

• Current consumption

  350 mA

• Adjacent channel rejection

  Typically ? 75 dB

• Intermodulation attenuation

  Typically ? 70 dB

• Receiving frequency

  Max. 3520 receiving frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels

• RF sensitivity

  < 2.5 V for 52 dBA eff S/N

• Squelch

  5 to 25 dBV in steps of 2 dB

• Equalizer

  Preset 1: Flat

  Preset 2: Low Cut (-3 dB at 180 Hz)

  Preset 3: Low Cut/High Boost (-3 dB at 180 Hz, +6 dB at 10 kHz)

  Preset 4: High Boost (+6 dB at 10 kHz)

• Temperature Range

  -10 ,C to +55 ,C

• Receiver Principle

  True diversity

  • Dimensions

    Approx. ?˜ 50 x 265 mm

  • Compander

    Sennheiser HDX

  • THD, total harmonic distortion

    0.9 %

  • Weight

    (incl. batteries) approx. 450 g

  • Signal-to-noise ratio

    ? 115 dBA

  • RF output power

    switchable: Low: typ. 10 mW, Standard: typ. 30 mW, High: typ. 50 mW

  • Switching bandwidth

    up to 88 MHz

  • Peak deviation

    ,48 kHz

  • Nominal deviation

    ,24 kHz

  • Operating time

    Typically 8 h

  • Modulation

    Wideband FM

  • Power supply

    2 AA batteries, 1.5 V or BA 2015 accupack

  • Current consumption

    at nominal voltage: typ. 180 mA

    with transmitter switched off: 25 ,?A

  • Powering

    3 V battery / 2.4 V rechargeable battery

  • Transmission frequency

    Max. 3520 frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels

  • AF frequency response

    80 ,?? 18,000 Hz

  • Temperature Range

    -10 ,C to +55 ,C

  • Frequency stability

    ,15 ppm
