QTX QX12A Active Loudspeaker - 178.755UK

SKU: 178.755UK
QTX

Active PA speaker units in a contemporary styled moulded ABS cabinet with integral carry handle and a constant directivity horn. The built-in mixer amplifier section delivers high output to the driver units to develop high SPLs.

Built-in amplifier with mixer section

Lightweight ported cabinet

Titanium compression driver

35mm internal top hat

Mic/line inputs with volume controls

Tone controls

Power supply 230Vac, 50Hz (IEC)

THD 0.1%

SNR 87dB

Dispersion 90 x 60 (H x V)

Impedance 4 Ohms

HF driver 38mm Ti compression driver

SPL @ 1W/1m 101dB

Crossover frequency 3.5kHz

Max. SPL 127dB

Power rms 200W

Power max. 400W

LF driver 300mm (12)

LF driver : coil size 52mm

HF driver : coil size 25mm

Frequency response 45Hz - 20kHz

Dimensions 345 x 565 x 320mm

Weight 13.2kg

Inputs Mic (combo), Line (RCA)
