QTX 4 Ohm 12 Driver for QR12A
SKU:
902.522UK
QTX
A range of chassis speakers to replace the main driver in the QTX Sound QR series active cabinets.
Vented magnets
Spade terminals
Impedance 4 ohms
Power max. 400W
Power rms 200W
Magnet weight 1.134kg (40oz)
Magnet size 20 x 140mm
Diameter 30cm (12)
Voice coil 52mm (2)
Frequency response 45Hz - 6kHz
SPL @ 1W/1m 98dB
Dimensions 129 x 307mm
Weight 4.02kg
£44.26
£59.00
