Neutrik NC10MXX-14-B, 8+2 Pole Male XLR Cable Plug

SKU: CONN530
Neutrik

Neutrik 8+2 Pole Male XLR Cable Plug NC10MXX-14-B

With the irresistible evolution of networking standards like Dante, AvB, AES67, Cobranet, etc. The RJ45 connector has become commonplace in the professional AV and lighting industry. The Neutrik 8 + 2 pole XLR offers a solution above that of the RJ45 with a rugged contact system, making the data connection road proven while offering the ability to carry power within the same connector. Neutrik have not simply squashed 10 pins into a standard insert, instead the 8 thinner pins are intended for twisted pair data up to 1Gb bandwidth while the 2 larger pins can be used for either a power supply or additional control data.

• Suitable for data offering CAT 5e performance and power up to 16A and 50V - exceeds PoE+ capabilities
• Superior ruggedness compared to RJ45 type connectors
• All metal housing offers best overall RF protection and electromagnetic shielding
• Easy to assemble 10 pole XLR connectors with secure locking and proven Neutrik chuck type strain relief
• Cable shield to shell connection: Selectable

• Contact resistance: 3m,?
• Dielectric strength: 1kVdc
• Insulation resistance: >10G,? , 0.1 (after damp heat test)
• Number of electronical contacts: 8 + 2
• Rated current per contact: 16A (power pins), 3A (data pins)
• Transmission performance: CAT 5e
• Overall cable diameter: 8-10mm
• Wire size: 2.5mm / AWG 14 (power pins), 1mm / AWG 18 (data pins)
