Lynx Pro-Audio RS2-3600 2 x 1800W Power Amplifier

SKU: LYNX015
Lynx Pro Audio

A range of lightweight 2 or 4 channel power amplifiers designed to meet the demands of installation or touring. The RS Series is based on an inverted mono-block approach offering an all-in-one power module that contains the entire amplifier assembly. The upside-down design reduces dust build-up to maximise cooling efficiency. The latest generation QuantaPulseT switching power supply allows to reach a new level of refined sensing and control of the power flow.

Class H design offers market leading audio quality and high efficiency
- 2 or 4 Channel models from 1000W up to 4000W
- Ultra-lightweight 6kg, compact package only 25cm deep
- Latest generation QuantaPulse, switch mode power supply
- Power Management System (PMS,) and Clip Limiter (ICL,)
- Upside down internal design to avoid fan dust accumulation
- Industry standard Neutrik XLR and SpeakON connectors
- Comprehensive protection set (ICL, PMS, SSP, turn-on, Temp, DC)
- Detented sealed potentiometers
- Dual or bridge mode operation
- Temperature controlled, rear to front cooling fan

- Power output - Stereo 8: 2 x 950Wrms
- Power output - Stereo 4: 2 x 1750Wrms
- Power output - Stereo 2: 2 x 1800Wrms
- Power output - Bridge 8: 3500Wrms
- Power output - Bridge 4: 3600Wrms
- Frequency response: 20Hz-20kHz
- Sensitivity: 2.2V
- Power supply: 170V-265V AC, 50/60Hz
- Dimensions: 483 x 88.9 x 254mm
- Weight: 6kg
