JBL CWT128-WRX
SKU:
JBL CWT128-WRX
Product Discontinued - Please contact us for alternatives
JBL
JBL CWT128-WRX
The JBL Crossfired Waveguide Technology CWT128 is a compact full-range 2-way system designed to provide extremely wide-angle coverage with maximum bandwidth and SPL in a single system package. The unique wide coverage pattern horn is designed to provide seamless coverage to 160-degrees horizontally. CWT128's small footprint makes the system ideal for nearly all architecturally sensitive environments, taking up about a third of the footprint of two speakers splayed side by side.
WRX Weather Resistant option for direct exposure or extreme environments.
- Seamless horizontal coverage across a full 160 degrees
- Compact size and small footprint make it ideal for architecturally sensitive environments
- Dual 205 mm (8 in) LF transducers
- Extremely wide-coverage
- 160, x 60, waveguide
- Dual 25 mm (1) exit, 38 mm (1.5) diaphragm compression driver
- Easy to install with 4 M10 attachment points built in across the top and sides
- 4 M8 points on the back panel accept OmniMountr wall mounting brackets
- WRC and WRX weather resistant versions are available upon request
- CWT128 is available in white - WH
| System Format | Extremely Wide Angle Coverage Dual 8 2-Way Loudspeaker System |
| Frequency Range (-10 dB) | 71 Hz - 20 kHz |
| Frequency Response (,3 dB) | 96 Hz - 19 kHz |
| Coverage Pattern | 160,x 60, |
| System Sensitivity | 94 dB SPL/1W/1m |
| Rated Maximum SPL (1m) | 129 dB |
| System Nominal Impedance | 8 Ohms |
| Long-Term System Power Rating | 450W (1800W Peak) |
| System Power Rating | 850W/1700W/3400W Continuous/Program/Peak |
| Crossover | 1.5 kHz |
| Low Frequency Driver | 2 x JBL 228J, 205 mm (8 in) SFGT driver with 64 mm (2.5 in) edge wound voice coil |
| High Frequency Driver | 2 x 2408H-1 25 mm (1 in) exit compression driver, 38 mm (1.5 in) voice coil |
| High-Frequency Waveguide | Crossfired Waveguide |
| Finish | Black DuraFlex finish. White (-WH) available upon request |
| Dimensions (W x H x D) | 811.28 x 259.59 x 300.74 mm (31.94 x 10.22 x 11.84 in) |
| Weight | 18.6 kg (40.9 lb) |
