JBL CONTROL19CST with 100V line transformer
SKU: JBL CONTROL19CST
Product Discontinued - Please contact us for alternatives

JBL

The Control 19CST uses advanced proprietary technologies to produce powerful bass from a low-profile in-ceiling design.

Frequency Range	42 Hz - 200 Hz
Power Capacity	200 W Continuous Program Power
Nominal Coverage Angle	180, conical coverage
Rated Maximum SPL	115 dB @ 1 m (3.3 ft) in ceiling near corner (???/2)
Nominal Impedance	8 ohms
Transformer Taps	70 V: 75 W, 30 W, 15 W & 7.5 W 100 V: 75 W, 30 W, & 15 W
Low Frequency	200 mm (8.0 in) Polypropelene cone. 38 mm (1.5 in) coil on aluminum former
Enclosure Material	Backcan: Formed steel Baffle/Rim: Medium impact polystyrene, fire-rated UL94V-0
Terminations	Removable locking connector with screw-down terminals. 2 input terminals and 2 loop-thru output terminals. Max. wire size 12 AWG (2.5 mm2)
Safety Agency Rating	In accordance with IEC60849 / EN60849. Suitable for use in air handling spaces, per U.L.-2043, U.L.-1480, NFPA90, NFPA70A.
Outside Dimensions (H x Dia)	345 x 345 mm (13.6 x 13.6 in) 318 mm (12.5 in) front of ceiling tile to back of backcan
Cutout Size (H x W)	305 mm (12.0 in)
Net Weight (ea)	6.3 kg (14 lb)
Shipping Weight (pair)	14.3 kg (32 lb)
Included Accessories	C-shaped support backing plate 2 tile support rails (fits both 2 x 4 ft or 600 x 1200 mm tiles) Cutout template Paint shield Removable locking wiring connector
