JBL AC16-WH 6.5" Ultra-Compact 2-Way Loudspeaker 160w 90x90° White

SKU: JBL0982
JBL

JBL AC16-WH

High output, 2-way loudspeaker systems combining flexibility with high fidelity

The AC16 is an ultra-compact full-range loudspeaker system designed to provide maximum bandwidth and SPL in a single system package and yet be visually unobtrusive. The enclosure design allows for installation very close to walls and ceilings making it an ideal choice for under balcony, column, or wall mounting. The high frequency device is a 1exit compression driver integrated into a newly designed 90 x 90 PT, (Progressive Transition) waveguide providing even coverage throughout the intended listening area. The combination exhibits smooth power response resulting in extremely natural voicing. The AC16 utilizes a 6.5Symmetrical Field Geometry (SFG,) LF Transducer with a copper-clad aluminum edge wound 2voice coil and a copper-clad pole piece that improves performance by reducing voice coil inductance and distortion.

The rugged multi-ply hardwood enclosure is designed to work in the vertical plane as well as in the horizontal plane. Mounting points are provided for an optional U-bracket and for an OmniMount type bracket. The AC16 is also equipped with attachment points located on the bottom of the enclosure for a stand mount accessory.

The rugged plywood enclosure features JBLs textured DuraFlex, finish and is equipped with a heavy duty powder coated steel, foam-backed grille.

• Product Features

  • 1Exit Compression Driver with 90 x 90 Coverage PT, Waveguide
  • 165 mm (6.5 in) LF transducer
  • Ultra compact enclosure
  • 320W Program
  • Dual Neutrik NL4 connectors plus screw terminal
  • Attachment points for optional U-bracket, third part OmniMount type bracket and stand mount accessory

• Applications

  • Performing Arts Facilities
  • Houses of Worship
  • Sports Facilities
  • Multi Media Spaces
  • Retail Spaces
  • Presentation Suites
  • Educational Facilities
  • Portable Audio-Visual Systems

General

• Frequency Range (-10 dB): 55 Hz - 20 kHz
• Frequency Response (+/-3 dB): 65 Hz - 18 kHz
• Horizontal Coverage: 90
• Vertical Coverage: 90
• Directivity Factor (Q): 7 (avg. 500 Hz - 16 kHz)
• Directivity Index (DI): 8 dB (avg. 500 Hz - 16 kHz)
• System Sensitivity: 90 dB SPL/1W/1m
• Rated Maximum SPL (1m)2: 110 dB
• System Nominal Impedance: 16 Ohms
• Long-Term System Power Rating (Continuous/Program/Peak): 160 W / 320 W / 640 W
• AES Standard Power Rating: 250 W
• Crossover: 2.4 kHz
• Transducers
  • Low Frequency Driver: 1 x JBL 226J, 165 mm (6.5 in) SFG, driver with 50 mm (2 in) edge wound voice coil
  • High Frequency Driver: 1 x 2414H 25 mm (1 in) exit compression driver, 25 mm (1 in) voice coil
  • High-Frequency Waveguide: PT-B99HF-1

Physical & Dimensions

• Enclosure: 12 mm and 15 mm exterior grade multi-ply hardwood plywood
• Suspension Attachment?
  • 5 x M8 points; 1 top, 3 bottom, 1 rear
  • 4 x M6 rear for OmniMount 30.0 and MultiMount
  • MM-022-BT, MM-024-BT, MM-020-CM
• Finish: Black DuraFlex, finish
• Optional Weather Resistant Versions: WRC & WRX available upon request
• Grille: Powder coated 16 gauge perforated steel, acoustically transparent foam backing (grille cloth backing on white units)
• Input Connectors: Neutrik Speakon NL4 (2 wired in parallel), plus CE-compliant covered barrier strip terminals. Barrier terminals accept up to 5.2 sq mm (10 AGW) wire or max width 9 mm (.375 in) spade lugs. NL4s +1/-1 in parallel with barrier strip (+2/-2 loop through).
• Environmental Specifications: Mil-Std 810; IPx3 per IEC529. For higher environmental ratings, use WRC or WRX.
• Dimensions (H x W x D): 381.0 x 199.4 x 226.1 mm
• Weight: 7.2 kg
