DAP DMX/AES-EBU IP cable 20m - 5P - Rean XLR/M 5P to XLR/F 5P - DAP

DAP FLR75 - DMX/AES-EBU 5 Pin IP65 Rean DMX Lead - 20M

roll over the image to zoom in

DAP FLR75 - DMX/AES-EBU 5 Pin IP65 Rean DMX Lead - 20M

DAP DMX/AES-EBU IP cable 20m - 5P - Rean XLR/M 5P to XLR/F 5P

SKU: FLR7520
DAP

The DAP FLR75 is a 20-metre IP65-rated DMX/AES-EBU cable designed long-distance, professional-grade digital signal transmission in outdoor and rugged environments. Constructed using DAP’s 110-ohm DIG-110 cable and protected with a polyurethane jacket, it ensures long-lasting durability and signal integrity.

Featuring Rean RCX5 connectors with silver-plated contacts and a black zinc housing, this cable offers low-impedance, high-reliability connections with a sleek professional finish. The braided shield minimizes signal interference, even over longer distances. Additional features include a transparent heat-shrink label sleeve for quick identification and a hook-and-loop fastener for neat, secure cable management.

£58.16
£77.54
Earn0
reward points
Add To Your Wishlist

Oh No! This product is out of stock. Would you like to know when it's avaliable again?

  • Product Features

    • IP65-Rated Protection: Ensures safe operation in outdoor or dusty environments.

    • 20 Metre Length: Great for long-distance runs between DMX controllers and fixtures.

    • 110-Ohm Digital Cable: Designed specifically for precise DMX and AES/EBU signal transmission.

    • Rean RCX5 Connectors: 5-pin professional-grade connectors with low-impedance signal paths.

    • Shielded Construction: Braided shielding prevents external signal interference.

    • Robust Design: Durable, black-plated zinc connector housing for a professional finish.

    • Identification & Management: Heat-shrink sleeve and hook-and-loop fastener included for convenience.

  • Technical Specification
    Specification
    Connector 1XLR 5 Pin
    Connector 2XLR 5 Pin
    Brand ConnectorsREAN
    Impedance110 Ohms
    Cable Length20m
    Pins5
    Conductor Resistance110 Ohms/km
    Conductor Capacitance35 pF/m
    Capacity Inner Conduct. Shield/Inner Conduct.52 pF/m
    Wire Connection1.6 mm2
    Outer Cable Diametre7mm
    Outer Isolation TypePur
    Contact TypeTin
    1st ShieldFoil
    2nd ShieldBraided Tinned Copper
    Shield Resistance12.5 Ohms/km
    Filler MaterialPaper
    Conductors2
    Conductor ConstructionStranded Core
    IP RatingIP65
    MaterialCopper, PUR
    ColourBlack
    Weight1.8kg
