DAP DMX/AES-EBU IP cable 20m - 3P - Rean XLR/M 3P to XLR/F 3P - DAP

DAP FLR73 - DMX/AES-EBU 3 Pin IP65 Rean DMX Lead - 20M

roll over the image to zoom in


DAP DMX/AES-EBU IP cable 20m - 3P - Rean XLR/M 3P to XLR/F 3P

SKU: FLR7320
DAP

The DAP FLR73 is a professional 20-metre IP65-rated DMX/AES-EBU cable built for reliable, high-quality digital signal transmission in live, outdoor, and industrial settings. Featuring a robust DAP DIG-110 digital cable core and Rean RCX3 connectors, it provides interference-free, low-impedance connections that perform flawlessly in harsh conditions.

This cable is shielded with a braided design and protected by a polyurethane jacket that ensures compliance with IP65 standards. The Rean RCX3 connectors use silver-plated contacts and black-plated zinc housings for superior conductivity and durability. It comes complete with a transparent heat-shrink sleeve for labeling and a hook-and-loop fastener to keep your setup tidy.


£55.58
£74.11
Earn0
reward points


Oh No! This product is out of stock. Would you like to know when it's avaliable again?

  • Product Features
    • 20-metre DMX/AES-EBU cable ideal for extended setups and stage rigs

    • 110-ohm DAP DIG-110 cable with polyurethane jacket for IP65 compliance

    • Rean RCX3 connectors provide IP65 protection and low-impedance performance

    • Braided shielding ensures interference-free signal transmission

    • Rugged black zinc housing combines professional look with reliability

    • Includes transparent heat-shrink sleeve for custom labelling

    • Convenient hook-and-loop fastener for tangle-free transport and storage

  • Technical Specification
    Specification
    Connector 1XLR 3 Pin
    Connector 2XLR 3 Pin
    Brand ConnectorsREAN
    Impedance110 Ohms
    Cable Length20m
    Pins3
    Conductor Resistance130 Ohms/km
    Conductor Capacitance20 pF/m
    Capacity Inner Conduct. Shield/Inner Conduct.65 pF/m
    Wire Connection1.8 mm2
    Outer Cable Diametre6mm
    Outer Isolation TypePur
    Contact TypeTin
    1st ShieldBraided
    Shield Resistance12.5 Ohms/km
    Filler MaterialCotton
    Conductors2
    Conductor ConstructionStranded Core
    IP RatingIP65
    MaterialCopper, Pur
    ColourBlack
    Weight1kg
