DAP DMX/AES-EBU cable 1.5m - 5p - REAN XLR/M 5P to XLR/F 5P - DAP

DAP FLR08 - DMX/AES-EBU 5 Pin Rean DMX Lead - 1.5m

roll over the image to zoom in

DAP FLR08 - DMX/AES-EBU 5 Pin Rean DMX Lead - 1.5m

DAP DMX/AES-EBU cable 1.5m - 5p - REAN XLR/M 5P to XLR/F 5P

SKU: FLR08150
DAP

The DAP FLR08 is a professional-grade 1.5-metre DMX/AES-EBU cable engineered for reliable and high-performance digital signal transmission. Built with DAP’s DIG-110 110-ohm digital cable and fitted with premium Rean RC5 connectors, this cable delivers low-impedance, interference-free connectivity essential for demanding lighting and audio environments.

The DIG-110 features a durable braided shield to ensure minimal signal loss and maximum protection from interference. The RC5 connectors offer silver-plated contacts for optimal signal clarity and a sleek, black zinc housing that combines durability with a professional appearance. For added convenience, each cable includes a transparent heat-shrink label sleeve for clear identification and a hook-and-loop fastener to keep your setup neat and organized.

Whether you’re working on stage, in the studio, or during live events, the FLR08 1.5m provides dependable, high-quality connections you can count on.

£12.78
£17.04
Earn0
reward points
Add To Your Wishlist

Oh No! This product is out of stock. Would you like to know when it's avaliable again?

  • Product Features

    • Professional-Grade Performance: Designed for high-quality DMX and AES/EBU digital signal transmission in demanding environments.

    • 1.5-Metre Length: Perfect for short-distance connections in racks, lighting setups, or compact stage configurations.

    • DAP DIG-110 Cable: 110-ohm digital cable with braided shielding for interference-free, low-impedance signal transfer.

    • Rean RC5 Connectors: Equipped with silver-plated contacts for enhanced signal clarity and dependable connectivity.

    • Durable Black Zinc Housing: Provides robust protection and a professional appearance.

    • Transparent Label Sleeve: Includes a heat-shrink sleeve for easy cable identification.

    • Hook-and-Loop Fastener: Ensures tidy cable management during setup, transport, and storage.

  • Technical Specification
    Specification
    Connector 1XLR 5 Pin
    Connector 2XLR 5 Pin
    Brand ConnectorsREAN
    Impedance110 Ohms
    Cable Length1.5m
    Pins5
    Conductor Resistance110 Ohms/km
    Conductor Capacitance35 pF/m
    Capacity Inner Conduct. Shield/Inner Conduct.52 pF/m
    Wire Connection3 mm2
    Outer Cable Diametre7mm
    Outer Isolation TypePE
    Contact TypeSilver Plated
    1st ShieldAluminium Foil
    2nd ShieldBraided Tinned Copper
    Shield Resistance12.5 Ohms/km
    Filler MaterialPaper
    Conductors4
    Conductor ConstructionStranded Core
    Maximum Ambient Temperature60 Degrees C
    Minimum Ambient Temperature-20 Degrees C
    IP RatingIP20
    MaterialCopper, PE
    ColourBlack
    Weight0.18kg
