Citronic RU210-H Tuneable Dual UHF Handheld Microphone System 171.970UK

SKU: 171.970UK
Citronic

Dual channel PLL tuneable UHF wireless system with 2 handheld transmitters. The receiver unit is compatible with standard 19 racks using the included rack ears and front mounting antenna accessories. The RF carrier frequency is selected on the receiver and synchronized to the transmitter via infra-red at the touch of a button. Up to 2 RU210 systems can be operated together on the EU licence-free band.

PLL tunable with 81 UHF frequencies

Pilot tone & mute circuit for stable signal

Rack-mounting accessories included

Supplied with mains adaptor and 4 x AA batteries

Licence free operation in UK & EU

Power supply12-18Vdc, 500mA (mains adaptor included)

Batteries4 x AA (2 per transmitter - included)

Carrier frequencies863 - 865MHz (81 selectable frequencies)

Dimensions : receiver44 x 409 x 190mm

Signal to noise ratio>105dB

THD<0.5% @ 1KHz

Image rejection>85dB

Range60m

Output impedance2.2k Ohms

Output level400mV (balanced), 200mV (unbalanced)

Weight : receiver1.37kg

Frequency response50Hz-18KHz 1 dB

Dimensions : transmitter265 x 49mm

Weight : transmitter330g (no battery)
