Citronic CASA-28BA Active Subwoofer 2 x 8" 400W 178.228UK

SKU: 178.228UK
Citronic

Compact slim profile active subwoofer cabinet with internal amplifier for mobile and fixed sound reinforcement. Line level input is connected via balanced XLR or 6.3mm jack with an XLR line output for cascading the signal onto further active cabinets. Preset DSP control accurately filters low frequencies to the class-D amplifier section to drive the twin 8 woofers up to 400Wrms output. A level control adjusts the output and the gain can be increased by engaging the Boost function. A phase switch can be used to correct time-alignment or out-of-phase situations. This sub unit can be postitioned flat to accept a 35mm pole to mount a full-range speaker or upright for a smaller footprint. The compact dimensions also make this a perfect option for hiding behind or underneath furnishsings in an installation.

Preset DSP sub frequency control

Dual 200mm (8) sub drivers

Internal 400Wrms class-D amplifier

35mm pole mount socket

Power supply 230Vac, 50Hz (IEC)

Construction 15mm MDF with durable texture paint finish

Hardware Integral carry handle & 35mm pole mount socket

Amplifier : construction Class-D

Line input Balanced XLR / 6.3mm jack

Line output Balanced XLR

Controls Master level, Phase switch, Boost switch

Drivers 2 x 200mm (8) woofers

Frequency response 55 - 150Hz

Output power rms 400W

Output power max. 700W

Peak output 1400W

SPL max. 122dB

Dimensions 475 x 450 x 250mm

Weight 15.7kg
