Chord NU1-N NU1 Neckband/Lavalier UHF System

SKU:
Chord

Chord NU1-N NU1 Neckband/Lavalier UHF System

Wireless microphone system with fixed UHF beltpack transmitter and half rack-width receiver. Supplied with a choice of neckband or lavalier microphones. The receiver unit is compatible with standard 19 racks using the included rack ears and front mounting antenna accessories.

Pilot tone & mute circuit for stable signal

Licence free operation in UK & EU

Rack-mounting accessories included

Supplied with mains adaptor and 2 x AA batteries

Power supply12-18Vdc, 350mA (mains adaptor included)

Batteries2 x AA (for transmitter - included)

Range60m

Signal to noise ratio>105dB

THD<0.5% @ 1kHz

Frequency response50Hz-18K 1 dB

Image rejection>85dB

Output impedance2.2k Ohms

Output level400mV (balanced), 200mV (unbalanced)

Dimensions : receiver44 x 198 x 190mm

Weight : receiver710g

Dimensions : transmitter205 x 68 x 25mm

Weight : transmitter76g (no battery) ,

Avaliable in the following frequencies: 863.1MHz or 864.1MHz.
