Chauvet Professional WELL COM V2 - Discontinued
SKU:
CHAUPRO WELLCOMV2
Product Discontinued - Please contact us for alternatives
Chauvet Professional
Chauvet Professional WELL COM V2
WELL Com 2 makes it possible to control your W-DMX enabled lights from a smartphone or a tablet. This wireless interface hands you full control over your fixtures including the ability to build and save static looks or timed chases via a free downloadable app that supports a full universe of?DMX and can save scenes and chases.
AT A GLANCE
Compact, easy-to-use battery powered Wi-Fi receiver and wireless WDMX transmitter combined with an Android or iOS, based control app
8 hours of usage on a full charge
Compatible with Android and iOS on both smartphones and tablets
Output can be used in wireless WDMX or wired DMX protocols
Full universe of DMX available for programming larger events
Built in color picker and color macros for use with RGB, RGBA, and RGBW wash fixtures
Program up to 24 steps per scene with selectable fade and hold times for building chases and cues
A total of 18 scenes available for playback
Easy to navigate user interface
Line-of-sight distance up to 200 m
SPECIFICATIONS
DYNAMIC EFFECTS
- Standalone Color Mixing: Yes
- Customizable Programs: Yes
- Recall Custom Programs: Yes
CONSTRUCTION / PHYSICAL
- Dimensions: 5.13 x 3.34 x 0.98 in (130.4 x 85 x 25 mm)
- Weight: 0.6 lb (0.3 kg)
- Exterior Color: Black
- Housing Material: High-impact flame-retardant polymer
CONNECTIONS
- Power Input: Micro USB-B Male
- Data Connectors: 5-pin XLR
- Cable Length (Dmx): 17 in (0.43 m)
- Cable Length (power): 3 ft (0.91 m)
CONTROL
- Control Protocol: DMX, W-DMX, Wi-fi
- DMX Channels: 512
ELECTRICAL
- Input Voltage: 5 VDC, 1600 mA (external power supply: 100-240 VAC 47/63 Hz)
- Power and Current: 7 W, 0.125 A @ 120 V, 60 Hz
- Power and Current: 6 W, 0.078 A @ 208 V, 60 Hz
- Power and Current: 6 W, 0.075 A @ 230 V, 50 Hz
BATTERY
- Battery type: Lithium Ion
- Rechargeable: Yes
- Battery Charge Time: 8 hours
- Battery Life: 8 hours
- Battery Power: 3.7 V, 6,000 mAh
CERTIFICATIONS / QUALIFICATIONS
- CE, FCC
- IP Rating: IP20, dry location
WHAT'S INCLUDED
- WELL COM
- USB-A Male to Micro USB-B Male (3 ft)
- 5-pin DMX adaptor
- External power supply
