Chauvet Professional Rogue Outcast 3 Spot (IP65) Moving Head

SKU: CHAUPRO ROGUEOUTCAST3SPOT
Chauvet Professional

Chauvet Professional Rogue Outcast 3 Spot (IP65 rated)

Rogue Outcast 3 Spot is a compact IP65 LED moving head that combines the latest lightweight alloy technology with a wheelhouse that delivers the color possibilities of dual color wheels, the dynamic morphing effects of dual gobo wheels, the beauty of smooth 16-bit fades, and a wide zoom range that adds flexibility to achieving desired coverage. Iris, prism and frost round out its effects, and its durable housing not only weathers outdoor elements but also brings advantages to indoor installations with a low-maintenance impervious design that withstands particulates such as fog and haze.

Optical

• Light Source: ?1 LED (CW) 300 W, (5 A), 7044 K, 50,000 hours life expectancy.
• Colour Temperature (at full): ?7044 K
• Front lens diameter: ?119 mm
• CRI: ?70
• Beam Angle: ?4.9 to 33.7
• Field Angle: ?5.5 to 38
• Cutoff Angle: ?5.6 to 38.7
• Zoom Range: ?4.9 to 38.7
• Lumens Source: ?20,000
• Lumens Output: ?14,989
• Illuminance (4.9): ?56,916lux @ 5 m
• Illuminance (38.7) 7,260 lux @ 5 m
• Selectable PWM: ?600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz

Dynamic Effects

• Pan and Tilt: ?540/270
• Pan and Tilt Ranges: ?180, 360, 540 pan/90, 180, 270 tilt
• Colours (1): ?7 + white, split colours, continuous scroll at variable speeds
• Colours (2): ?7 + white, split colours, continuous scroll at variable speeds
• Gobos (1): ?7 + open (7 metal), rotating, interchangeable, indexing,
• slot-n-lock, continuous scroll at variable speeds
• Gobos (2): ?8 + open (8 metal), continuous scroll at variable speeds
• Gobo Size: ?Gobo Wheel 1 (rotating); size: ?25.5 mm (outside), 14.8
• mm (image), 0.6 mm (max. thickness)
• Gobo Size: ?Gobo Wheel 2 (static): ?size: ?24 mm (outside), 16 mm
• (image), 0.6 mm (max. thickness)
• Dimmer: ?Electronic
• Shutter/Strobe: ?Electronic
• Zoom: ?Motorized
• Focus: ?Motorized
• Frost: ?Motorized
• Iris: ?Motorized
• Prism: ?5 Facets, motorized, rotating
• Strobe Rate: ?0 to 20 Hz
• Move in Black: ?Yes?

Connections

• Power Connection: ?Edison (local) plug to Seetronic Powerkon IP65
• Power Input: ?Seetronic Powerkon IP65
• Power Output: ?Seetronic Powerkon IP65
• Data Connectors: ?5-pin XLR
• Cable Length (power): ?5 ft (1.5 m)

Control

• Control Protocol: ?DMX, RDM
• DMX Channels: ?20 or 25
• Modes/Personalities: ?2 personalities (20, 25)

Electrical

• Input Voltage: ?100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: ?3 units @ 120 V; 5 units @ 208 V; 6 units @ 230 V
• Power and Current: ?506 W, 4.24 A @ 120 V, 60 Hz
• Power and Current: ?493 W, 2.43 A @ 208 V, 60 Hz
• Power and Current: ?494 W, 2.19 A @ 230 V, 50 Hz

Certifications / Qualifications

• CE, MET, UKCA
• IP Rating: ?IP65, temporary outdoor/ wet, with pressure equalizing
• M12 GORE valve
• Temperature (Ambient): ?-14 F to 113 F (-10 C to 45 C)
• Maximum Exterior Surface Temperature (Tc): ?80 C / 176 F
• Maximum Ambient Temperature (ta): ?45 C / 113 F

Physical & Dimensions

• Dimensions: ?14.41 x 9.61 x 25.16 in (366 x 244 x 639 mm)
• Weight: ?51 lb (23.2 kg)
• Exterior Colour: ?Black
• Housing Material: ?High-impact flame-retardant polymer
